Data Sheet

©Axell Wireless | www.axellwireless.com | [e-mail] | Version: 3.5| E & O.E. All specifications are subject to change without prior notice.
2
Technical specifications
RF Parameters
Frequency bands
68-500 / 380-2200 / 700-2700 MHz
Gain flatness
typical 2 dB (p-p)
Nominal RF input power
+10 dBm composite power
Absolute maximum RF input power
+23 dBm composite power
Number of optical modules
1-24 (depends on low/high power configuration)
MBF-40 (high power)
MBF-20 (low power)
The table to the left lists the
various high (MBF-40) and
low (MBF-20) power remote
unit configurations and how it
affects the total number of
links supported.
For example: if the OMU II
supports two high power fibre
remotes, then the available
low power links = 20
8
0
7
4
6
8
5
12
4
16
3
16
2
20
1
20
0
24
Laser class
Class 1
Optical module electrical specification
Optical wavelength Downlink (± 10 nm)
1310
Optical wavelength Uplink (± 3 nm)
1510 or 1530 or 1550 or 1570 or 1590
Maximum optical input power
+5 dBm
Output power (Tx) max
+7 dBm
Automatic fibre optic loss compensation
Yes
Optical Splitter Module (OSM) electrical specification
Optical splitter (OSM) input power
+5 ± 1 dBm
Insertion loss
7dBo
Power requirements
Power requirements
230/115 VAC, 50/60 Hz,-48 VDC
Power consumption
Typical 50 W (fully equipped)
External electrical interfaces
Local maintenance terminal
Ethernet, USB, RS232
RF ports
N-type Connector Female for 1-2 sectors. SMA connectors for 8 sectors
Optical ports
SC/APC
AC/DC mains input
AC: IEC Connector with main lead supplied according to the region. DC: flying
leads for connection to terminal block
External alarms
Via Front panel
Modem connector
RJ45 for wireless modem , RJ11 for PSTN modem
Modem antenna connector
(Wireless modem)
SMA
Ethernet connector
RJ45
Mechanical specifications
Dimensions (W x H x D)
17.5 x 5.2 x 11.4 in (444 x 132.5 x 291 mm) 19” rack
Weight
33 lbs (15 kg) (fully equipped)
IP rating
IP20
Environmental
Operating temperature
+41 to 113° F (+5 to +45°C)
