Appendix A: Specifications
This appendix provides the electrical, mechanical and environmental specifications of the
Axell D-MBR 3007-3008-PS-NFPA.
Electrical Downlink Uplink
Frequency Range:
SMR 700MHz ,D block
SMR 700MHz
SMR 800MHz
758 - 763 MHz
763 - 775 MHz
851 - 861 MHz
788 - 793 MHz
793 - 805 MHz
806 - 816 MHz
Passband Max Gain 85dB
Passband attenuation range 30dB @ 1dB steps 20dB @ 1dB steps
Passband Ripple ± 2.5 dB ± 2.5 dB
Gain attenuation range 30dB 20dB
Filter Bandwidth (SMR 700MHz) (*)
Filter Bandwidth (SMR 800MHz) (*)
Programmable 12.5KHz to 1MHz at 12.5KHz
steps, 1MHz-17MHz at 200KHz steps
Programmable 12.5KHz to 1MHz at 12.5KHz
steps, 1MHz-10MHz at 200KHz steps
Number of filters( SMR 700& 800) 12
Composite Output Power SMR700MHz +30 dBm +27 dBm
Composite Output Power SMR800MHz +30 dBm +27 dBm
Noise Figure @ Maximum Gain 5.0 dB
General
Dimensions W x D x H 13.78” x 18.1” x 5.7” (350 mm x 460 mm x
145 mm)
Power Supply 90 to 260 VAC or 48VDC
Power Consumption <130 W
Total RF Input Power (no damage) +10 dBm
Impedance Level 50 Ohm
RF Connector N-type, Female
VSWR 1.5:1 maximum
Compliance IC/FCC
Environmental
Operating Temperature -5 to 122° F (-10° C to +50° C)
Humidity 10% to 90% Condensed
Weight 28.8 lbs. (13kg)
Enclosure Aluminum (NEMA4/IP-65)
