3 Installing the Repeater

3.1 Repeater Pre-Installation Requirements

3.1.1 Safety Guidelines

Before installing the Repeater, review the following safety information:

• Follow all local safety regulations when installing the Repeater.

• Only qualified personnel are authorized to install and maintain the Repeater.

• Ground the Repeater with the grounding bolt located on the external lower side of

the Repeater).

• Do not use the grounding bolt to connect external devices.

• Follow Electro-Static Discharge (ESD) precautions.

• Use low loss cables to connect the antennas to the Repeater.

3.1.2 Required BTS Information

Required BTS Information

• BTS channels

• BTS output power per channel

• BTS antenna gain

• BTS antenna height

• Distance from Repeater site to BTS

3.1.3 Installation Location and Environment

WARNINGS!!!

the Repeater must always be installed vertically and top-down – with the connectors

on the underside for protection .

Horizontal installation on a bench for long time may cause damage to the Repeater

due to over-heating.

The following criteria should be considered when selecting the Repeater installation site

location:

• Application type – indoor or outdoor

• Distance from antenna site - It is recommended that the installation location be as

close as possible to the antenna site in order to maintain the cable loss to a

minimum.

• General surroundings and accessibility of location

• In outdoor applications it is recommended to install a cabinet or a shielding sunroof

for further protection against weather wear.

• Use a suitable mounting surface, such as a flat back rigid wall.

• The Repeater is convection cooled so airflow and alternation should be possible.

• Install the Repeater in a shielded, ventilated, and easy-to-reach area – preferably at

eye level.

• Ensure that adequate airflow and ventilation within the rack and around the installed

components so that the safety of the equipment is not compromised.
