1.1 Main Features
• Class A or B- signal booster ( based on filter setting) for SMR and public safety
networks
• Supports APCO 25 phase 1 and 2 for public safety networks
• NFPA 72-2010, Chapter 24 and IFC 510.1 Compliant
• Support of 700MHz D block for LTE network
• SMR 700MHz and 800MHz bands in a single enclosure
• RF Gain: Up to 85dB Gain
• SALC-Smart ALC mechanism to protect the digital signal booster from oscillation
and shutdown the signal booster when required
• Output Power per band: DL +30dBm; UL +24dBm
• Composite Output Power: DL +33dBm; UL +27dBm
• Web based management GUI, SNMP traps
• Patented DSP filtering™ technology
• Supports up to 12 independent filters; user programmable bandwidth /
frequency
• For SMR700: Programmable 12.5 kHz to 17MHz
• For SMR800: Programmable 12.5 kHz to 10MHz
• User-selectable adjacent channel rejection and time delay to minimize
interference
• IP65 (NEMA 4) Enclosure
