User's Manual

Maintenance Handbook
Baltimore Radio Repeater System
Handbook No. 60-166801HBKM Page 11 of 23
3.8 Off-Air (M.O.C.E) Remote Repeater Parts List (60-166801)
AFL Part No. Part Description Qty.
02-013401 6 POLE SPECTRUM DIVIDING COMBLINE FILTER 4
05-002603 UHF 3dB SPLITTER 2
07-002902 POWER MONITOR 20dB OUTPUT 350-550MHz 2
07-002908 POWER MONITOR 30dB OUTPUT 350-550MHz 2
10-000901 SWITCHED ATTENUATOR 0-15dB 2
10-001205 REMOTE SWITCHED ATTENUATOR 0-15dB 1
11-007302 LOW NOISE AMPLIFIER 20dB GAIN 5
12-021601 AMPLIFIER 5W 1
12-021704 POWER AMPLIFIER (LINEARIZED ) 20W 2
12-021801 POWER AMPLIFIER 1
13-003011 DC-DC CONVERTOR BOARD 1
13-003301 MAINS FILTER 8AMP 1
17-000126 CELL ENHANCER ID LABEL 1
17-000526 GASKET FOR HEATSINK 2
17-001109 AGC UNIT DETECTOR 2
17-001201 AGC UNIT ATTENUATOR 2
17-001528 BLANKING PLATE GASKET 2
17-002020 CELL ENHANCER BODY 1
17-002021 EQUIPMENT MOUNTING PLATE 1
17-003042 CHANNEL MODULE 450-475MHz, 1.25MHz BW 2
20-001601 12V RELAY BOARD 4
20-001602 24V RELAY BOARD 1
80-031820 HEATSINK FOR 20W POWER AMPLIFIER 2
80-032320 HEATSINK FOR 10W POWER AMPLIFIER 1
80-310420 HEATSINK FOR POWER SUPPLY 1
90-100010 MAINS LEAD '6 AMP' FOR USA 1
90-200004 DC I/P LEADS, FREE SOCKET 1
91-030002 N ADAPTOR PANEL FEMALE:FEMALE 2
91-130001 SMA ADAPTOR 'T' ALL FEMALE 2
91-500011 3 POLE PANEL PLUG SEALED IP68 1
91-500013 2 POLE PANEL PLUG SEALED IP68 1
91-500015 CAP FOR PANEL PLUG 3
91-500043 25 POLE PANEL PLUG SEALED IP68 1
91-510037 25 POLE FREE SOCKET SEALED IP68 1
91-520033 25 POLE CONNECTOR SOCKET CONTACTS 25
91-520034 25 POLE CONNECTOR PIN CONTACTS 25
91-600014 'D' 9 WAY SOCKET 8
91-620001 'D' 25 WAY SOCKET 2
91-620006 D' 25 WAY CONNECTOR SHELL 2
91-640004 LARGE PIN FOR 7 WAY 2W5 MIXED D TYPE SOCKET 4
91-660001 7 WAY 2W5 MIXED D TYPE SOCKET 2
91-800003 10 WAY KRONE MODULE 2
93-930003 1W LOAD TERMINATION 2
96-110047 20A ATO FUSE 2
96-300054 POWER SUPPLY UNIT 400w 1
96-700034 LED RED 5mm IP67 1
96-700035 LED GREEN 5mm IP67 1
96-900018 AC TRIP SWITCH (5 AMP M.C.B.) 1
96-920037 THERMAL SWITCH 70c N/C 1A TO-220 1
97-000001 WALL MOUNTING BRACKETS 1
97-300010 MAINS SUPPLY INPUT COVER 2
97-300028 DC SWITCH AND FUSE BOX 1
97-400010 BLACK PLASTIC HANDLE 50mm HIGH 2
97-900004 RUBBER FOOT FOR CELL ENHANCER 4
