7.2 Tx Hybrid Coupler (05-000101)
7.2.1 Description
The Hybrid Combiner used is a device for accurately matching two or more RF signals to single
or multiple ports, whilst maintaining an accurate 50Ω load to all inputs/outputs and ensuring
that the VSWR and insertion losses are kept to a minimum. Any unused ports will be terminated
with an appropriate 50Ω load.
7.2.2 Technical Specification
PARAMETER SPECIFICATION
Frequency range: ƒ
o
± 10% (50 – 500 MHz)
Bandwidth: ƒ
o
± 10%
Inputs/Outputs: 2 each
Insertion Loss: <3.3 dB
Isolation between Input/Output ports: >27 dB
Return Loss (VSWR) – Input/Output: 1.3:1
Impedance: 50
operation: -10°C to +60°C
Temperature range
storage: -20°C to +70°C
MTBF: >180,000 hours
Power Rating – Splitter: Up to 150 Watts (load dependant)
Power Rating – Combiner: Available up to 100 Watts
Environmental: IP54
Connectors: ‘N’ female
Dimensions: 118 x 102 x 35 mm (incl. connectors)
Weight: 0.5 kg
