6.2.3 Alarm/Monitor Shelf Parts List
AFL Part Nō. Part Description Qty.
19-000724 1U 19" UNIT FRONT PANEL FAB 1
19-000725 1U 19" UNIT 400 DEEP CHASSIS + BKT 1
19-000826 2U,3U,4U 19" UNIT 400 DEEP LID 1
20-001601 12V RELAY BOARD 4
91-520003 POWER SWITCHD/FUSED MAINS INL. 1
91-520005 MAINS LEAD 1
91-520010 MAINS RETAINING CLIP 1
91-600014 'D' 9 WAY SOCKET S/B (NON FILTERED) 8
91-600015 'D' 9 WAY PLUG S/B (NON FILTERED) 8
96-300072 12V POWER SUPPLY TML15112C 1
96-600001 INSULATING BOOT LARGE 1
96-700034 LED RED 5mm IP67 8
96-700035 LED GREEN 5mm IP67 1
