5.3.5 VHF Uplink Crystal Splitter Parts List
AFL Part Nō. Part Description Qty.
01-002503 FILTER VHF H/B 6 SMA S 100W 2
01-003105 SD NOTCH FILT.N 6 SECT.VHF H/B SMA 1
05-002901 3dB BROADBAND SPLITTER SMA 1WATT 1
19-000921K 3U CHASSIS KIT (400mm deep) 1
91-030002 N ADAPTOR PANEL FEMALE:FEMALE 10
91-130001 SMA ADAPT 'T' ALL FEMALE 3 GHz 8
93-980123 161.520MHz CRYSTAL FILT FAN4M52500 1
93-980125 153.785MHz CRYSTAL FILT FAN4M52500 1
93-980126 154.325MHz CRYSTAL FILT FAN4M52500 1
93-980127 154.680MHz CRYSTAL FILT FAN4M52500 1
93-980128 155.235MHz CRYSTAL FILT FAN4M52500 1
93-980129 155.280MHz CRYSTAL FILT FAN4M52500 1
93-980130 158.865MHz CRYSTAL FILT FAN4M52500 1
93-980131 159.090MHz CRYSTAL FILT FAN4M52500 1
93-980132 159.210MHz CRYSTAL FILT FAN4M52500 1
