4.2.3 VHF Duplex BDA Mechanical Specification
PARAMETER SPECIFICATION
Height: Standard Eurorack
Width: 19" (482.6mm)
Rack
Depth: 600mm (800 optional)
Height: 3U
Width: 19" (482.6mm)
Shelves:
Depth:
<400mm(excluding heatsinks, connectors,
handles and feet)
operational: -10°C to +55°C Temperature
range:
storage: -40°C to +70°C
Weight: <15kg
Humidity: 5 – 95% non-condensing
RF Connectors: N type female
Environmental protection: IP54
Case: Alocrom 1200
Heatsinks: Matt black
Handles: Silver anodised alloy
Finish:
Fascia: Painted to RAL 7035
Supply Cable:
Unit supplied with suitable supply input
leads, connector and specified length of
cable (where appropriate)
