Appendix A - Specifications
The following tables provide specifications for all models.
Electrical Specifications
Operator Duplex
5MHz
3MHz
Frequency range
450-470MHz
470-512MHz
Output power/carrier (DL)
+36dBm 1 carrier
+33dBm 2 carriers
+30dBm 4 carriers
+40 dBm 1 carrier
+30 dBm 2 carriers
+27 dBm 4 carriers
Gain
55 – 85 dB, in 1 dB steps
55 – 85 dB, in 1 dB steps
Operator bandwidth
2.5MHz
1.5MHz
Duplex distance
5MHz
3MHz
Number of Channels
Up to 8
Impedance
50 
IP3
+68 dBm, typical
Noise figure (UL)
4.5 dB at maximum gain
Selectivity
According to ETSI TS 101-789-1
Group delay
< 12 µs max (14 µs at high selectivity)
ALC
Time slot based
Spurious Emissions from
RF port
< -13dBm
Intermodulation Products
< -60dBc (according to TS 101-789-1)
Power Requirements
5MHz
3MHz
Power Requirements
115VAC 60Hz or –48VDC
Power Consumption
180 Watts typical
External Connections
Local Maintenance port
RS232
RF port
N-type Female
AC/DC input
Circular, 3-pin
RF Mechanical Specification
5MHz
3MHz
Dimensions
600 x 400 x 310 mm (24 x 16 x 12.2 in.) (h x w x d)
Enclosure
IP65
IP65
Weight
30kg/66lbs
48kg (106 lbs)
Cooling
Convection
Convection
RF Environmental Specification
Operating temperature
-10 to +50 °C (-14 to +122 °F)
Storage temperature
-30 to 70° C (-58 to 158° F)
Humidity Condensed
10% – 90%
