User Manual

AXELL CSR 3604-3304 UHF REPEATER

PRODUCT DESCRIPTION AND USER’S MANUAL

To switch the repeater ON

1. Open repeater door to access switches.

2. Set to ON both Power and Battery switches (located inside the repeater).

3. Connect the supplied power cable between the Repeater Power connector and the

circuit breaker.

4. Turn the repeater on from the circuit breaker.

5. Verify the LEDs from the following internal modules are indicating correct operation

(section 8.1):

 Control module.

 Power supply modules

NOTE: To switch power OFF – set battery switch to OFF and power switch to Standby.
