6.6 Integration into the AEM

When the repeater has been installed at site and the remote communication has been

enabled, the repeater can be integrated to the Axell Element Manager. This is done by the

operator of the AEM. After entering the telephone number to the repeater, the AEM dials up

the repeater, downloads all the repeater parameters and statuses into a database. When all

parameters have been downloaded, the AEM configures the repeater with the telephone

number where alarms and reports should be sent, and optionally with a secondary

telephone number where the repeater can dial in case connection to primary number fails.

When heartbeat reports and alarms are sent from the repeater to the AEM also the latest

information about the status and RF-configuration is included. This means that the AEM

operator always has information about the current status in the AEM database (and do not

need to call the repeater to find this out).

NOTE: Once the repeater is integrated to the AEM, all changes to the repeater should

preferably be done from the Axell Element Manager in order to ensure that the database

always contains correct information.
