4.6 800MHz Cell Enhancer Parts List
AFL Part Nō. Part Description Qty.
02-004502 4P C/L SD FILTER 920MHz (3MHz B/W) SMA 5
02-007206 900MHz 8 POLE 15-25MHz B/W "SMA" 2
05-002602 900MHz SPLITTER/COMBINER, 20W 4
05-003801 3WAY GEN.SPLIT 900MHz GEN.ASS 2
10-000701 1/4W0-30dB SWITCHED ATTENUATOR 2
11-005902 900MHz LOW NOISE AMP WITH RELAY ASS 3
11-006702 GA 800-1000MHz LNA 29dB 3
12-018002 PA 800-960MHz 20W CLASS A 2
12-021901 POWER AMPLIFIER 900MHz 1W +12V 1
12-021902 POWER AMPLIFIER 900MHz 2W +12V 1
14-000225 CASE RAIL LONG R.S.A./R.F.A. 4
17-002101 CHANNEL CONTROL MODULE 1
17-002103 26WAY RIBBON CABLE LEAD 3
17-009127 CHAN MOD 810-860MHz 30KHz 8p TCXO 3
20-001601 12V RELAY BOARD 1
50-012825 CCE RACK MOUNTED HEATSINK BRACKET 4
50-012843 CCE RACK 8U CHASSIS 400mm DEEP 1
50-012844 CCE RACK LID 400mm DEEP 1
50-027720 RACK MTD CHAN C.E. MODIFIED HEATSINK 2
80-008901 12V RELAY PCB ASSEMBLY 1
80-090822 C/E 8U FRONT PANEL, AFL (RAL7035) 1
91-030002 N ADAPTOR PANEL FEMALE:FEMALE 4
91-130005 SMA BULKHEAD ADAPTOR F/F 4
91-500001 POWER PLG 3 PIN PNL.MOUNT NC-X 1
91-510003 3 PIN R.ANGLE FREE SOC.NC-X. 1
91-510032 20A SOCKET CONTACT PIN 4
91-600007 'D' 9 WAY BLACK SHELL 8
91-600014 'D' 9 WAY SOCKET S/B (NON FILTERED) 8
91-600015 'D' 9 WAY PLUG S/B (NON FILTERED) 1
91-660001 2W5 MIXED D TYPE SOCKET (7 WAY) 2
96-700034 LED RED 5mm IP67 1
96-700035 LED GREEN 5mm IP67 1
96-920043 20A CIRCUIT BREAKER (ETA 2-5700) 1
97-400005 HANDLE TYPE H6802 3U [ALLOY] 2
99-200008 DANGER HIGH VOLTAGE LABEL 2 x 2' 1
99-200017 CAUTION HEAVY LABEL 75 x 55mm 2
