User Manual
Table Of Contents
- AMENDMENT LIST RECORD SHEET
- INTRODUCTION
- 1.SAFETY CONSIDERATIONS
- 2.OVERVIEW/SYSTEM DESCRIPTION
- 3.SPECIFICATION
- 4.SYSTEM DRAWINGS
- 5.SUB-UNIT MODULES
- 5.1Downlink Channelised Cell Enhancer 60-060602 (5U chassis)
- 5.1.1Bandpass Filters (02-010701)
- 5.1.2UHF 3dB Splitter (05-002603)
- 5.1.33dB UHF Splitter (05-002603)
- 5.1.4¼Watt 0- -30dB Switched Attenuator \(10-00
- 5.1.5Low Noise Amplifiers (11-007302 & 11-007402)
- 5.1.5.1Description
- 5.1.5.2Technical Specification, (11-007302)
- 5.1.5.3Technical Specification (11-007402)
- 5.1.5.3Drg. No. 11-007302, LNA Assembly With Alarm Relay
- 5.1.5.4Drg. No. 11-007370, LNA RF Circuit Diagram
- 5.1.5.5Drg. No. 11-007371, LNA DC Wiring Diagram
- 5.1.5.6Drg. No. 11-003971, LNA DC Circuit Diagram
- 5.1.610Watt Power Amplifier (12-001901)
- 5.1.73 Stage Amplifier Alarm Boards (12-002201)
- 5.1.8Dual DC/DC Converter (13-001803)
- 5.1.9Channel Selective Module (17-003012)
- 5.1.1024V Relay Board (20-001602)
- 5.2Uplink Channelised Cell Enhancer 50-060603 (5U chassis)
- 5.3Power Supply Shelf 50-060604 (4U chassis)
- 5.1Downlink Channelised Cell Enhancer 60-060602 (5U chassis)
- 6.INSTALLATION
- 7.MAINTENANCE
- APPENDIX AINITIAL EQUIPMENT SET-UP CALCULATIONS
5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
6 of 54
Glossary of Terms
Repeater or
Cell Enhancer A Radio Frequency (RF) amplifier which can simultaneously
amplify and re-broadcast Mobile Station (MS) and Base
Transceiver Station (BTS) signals.
Band Selective Repeater A Cell Enhancer designed for operation on a range of channels
within a specified frequency band.
Channel Selective
Repeater A Cell Enhancer, designed for operation on specified channel(s)
within a specified frequency band. Channel frequencies may be
factory set, remotely set by computer, or on-site programmable.
BTS Base Transceiver Station
C/NR Carrier-to-Noise Ratio
Downlink (D.L.) RF signals transmitted from the BTS and to the MS
Uplink (U.L.) RF signals transmitted from the MS to the BTS
EMC Electromagnetic Compatibility
GND Ground
DC Direct Current
AC Alternating Current
ID Identification Number
OIP3 Output Third Order Intercept Point = RF
out
+(C/I)/2
LED Light Emitting Diode
M.S. Mobile Station
N/A Not Applicable
N/C No Connection
NF Noise Figure
RF Radio Frequency
Rx Receiver
Tx Transmitter
S/N Serial Number
