5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
47 of 54
5.3.2 48V/8A DC Power Supply Module (96-300056)
5.3.2.1 Description
This PSU module is similar in size and type to the 24V module, being a multi-mains-
voltage switch mode unit but having a 48V DC output. The unit is used to power the
remote amplifier unit via the DC Tap Module (see section 5.2.1). A small volt drop from
the 48V PSU to the remote cell enhancer is expected so that the DC voltage may be easily
converted to 24V to power the remote enhancers’s electronics.
5.3.2.2 Technical Specification
AC Input Supply
110 or 220V nominal
Voltages:
90 to 132 or 180 to 264V (absolute limits)
Frequency: 47 to 63Hz
DC Output Supply:
48V DC (nominal)
Voltage:
45-50V (absolute limits)
Maximum Output Current: 6A
operation:
-10ΒC to +55ΒC
Temperature
range
storage:
-40ΒC to +70ΒC
All other modules in this shelf have been described elsewhere in this document.
