5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
46 of 54
5.3 Power Supply Shelf 50-060604 (4U chassis)
5.3.1 24V 410W Flat-Pack Power Supply (96-300054)
5.3.1.1 Description
The power supply unit is a switched-mode type capable of supplying 24V DC at 17.0Amps
continuously. Equipment of this type typically requires approximately 5-7.0 Amps at 24V
DC, so the PSU will be used conservatively ensuring a long operational lifetime.
No routine maintenance of the PSU is required. If a fault is suspected, then the output
voltage from the power supply may be measured on its output terminals. This is typically set
to 24.5V.
All the PSU’s used in AFL Cell Enhancers are capable of operation from either 110 or 220V
nominal AC supplies. The line voltage is sensed automatically, so no adjustment or link
setting is needed by the operator. The PSU modules are O.E.M devices and therefore no
drawings are available.
5.3.1.2 Technical Specification
AC Input Supply:
Voltage: 110 or 220V nominal - 90 to 132 or 180 to
264V (single phase, absolute limits)
Frequency: 47 to 63Hz
DC Output Supply:
Voltage: 24V DC (nominal), 22 to 26V
(absolute limits)
Current: 17.0A
operational:
-10ΒC to +55ΒC
Temperature
range:
storage:
-40ΒC to +70ΒC
