5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
32 of 54
5.1.7.2 Technical Specification
PARAMETER SPECIFICATION
Operating voltage: 8 to 30V (floating earth)
Alarm Threshold: Vcc - 1.20 volt +15%
Alarm output relay contacts:
Max. switch current: 1.0Amp
Max. switch volts: 120Vdc/60VA
Max. switch power: 24W/60VA
Min. switch load: 10.0µA/10.0mV
Relay isolation: 1.5kV
Mechanical life:
>2x10
7
operations
Relay approval: BT type 56
Connector details: 15-way 0.1" pitch
operational: -10°C to +55°C
Temperature range:
storage: -40°C to +70°C
74 x 56mm (3 stage)
PCB Size:
54 x 56mm (1 stage)
