5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
27 of 54
5.1.6 10Watt Power Amplifier (12-001901)
5.1.6.1 Description
The power amplifier fitted to this unit is a multi-stage, solid state class A power
amplifier. All the semi-conductor devices are very conservatively rated to ensure low
device junction temperatures and a long, trouble free working lifetime. The amplifier was
originally designed to have a 20W power output, but in this instance, the biasing is
changed to give the device a 10W rating.
The power amplifier should require no maintenance over its operating life. Under no
circumstances should the cover be removed or the side adjustments disturbed unless it is
certain that the amplifier has failed; since it is critically aligned during manufacture and
any re-alignment will require extensive test equipment.
5.1.6.2 Technical Specification
PARAMETER SPECIFICATION
Frequency Range: 400 - 500MHz (tuned to spec.)
Bandwidth: 20MHz (typical, tuneable)
Maximum Output Power: >10W
Gain: 28dB
3rd Order Intercept Point: <+51dBm
1dB Compression Point: <+40dBm
VSWR: better than 1.45:1
Connectors: SMA female
Supply: 2.5A @ 24V DC
operational
:
-10°C to +55°C
Temperature range:
storage: -40°C to +70°C
Size: 276 x 78 x 40mm (case only)
Weight: 1.5 kg (excluding heatsink)
