5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
22 of 54
5.1.5 Low Noise Amplifiers (11-007302 & 11-007402)
5.1.5.1 Description
The low noise amplifiers used are double stage solid-state low-noise amplifiers. Class A
circuitry is used in the units to ensure excellent linearity over a very wide dynamic range.
The active devices are very moderately rated to provide a long trouble-free working life.
There are no adjustments on these amplifiers, and in the unlikely event of failure then the
entire amplifier should be replaced. The two amplifiers are very similar in construction,
the only difference is the biasing, which changes the gain figure, see tables below.
5.1.5.2 Technical Specification, (11-007302)
PARAMETER SPECIFICATION
Frequency range: 380-500MHz
Bandwidth: <140MHz
Gain: 20-22dB
1dB Compression Point: +23.5dB (typical)
3rd order intercept: +36dB (typical)
Input/Output return loss: >20dB
Noise figure: <1.3dB
Connectors: SMA female
Supply: 200-230mA @ 24V DC
operational: -10°C to +55°C
Temperature range:
storage: -30°C to +70°C
Weight: <300gms
Size: 90 x 55 x 30.2 (case only)
5.1.5.3 Technical Specification (11-007402)
PARAMETER SPECIFICATION
Frequency range: 380-500MHz
Bandwidth: <140MHz
Gain: 30-32dB
1dB Compression Point: +22dBm (typical)
3rd order intercept: +34-35dBm (typical)
Input/Output return loss: >20dB
Noise figure: <1.3dB
Connectors: SMA female
Supply: 300-330mA @ 24V DC
operational: -10°C to +55°C
Temperature range:
storage: -30°C to +70°C
Weight: <300gms
Size: 90 x 55 x 30.2 (case only)
