5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
15 of 54
3.3 Mechanical Specification
Height: Eurorack Shelves(1U=44.5mm)
Width: 19"Case Size:
Depth: <500mm
(excluding heatsinks, connectors, handles
and feet)
operational: -10°C to +55°C
Temperature Range:
storage: -40°C to +70°C
Weight: <30kg* (approximately)
Humidity: 5 – 95% non-condensing
RF Connectors: N type female
Environmental Protection: IP54
Case: Alocrom
Heatsinks: Matt blackFinish:
Handles: Alocrom
Supply Cable:
Unit supplied with suitable supply input
leads with connector and specified length
of cable (where appropriate)
* Note: Individual shelf weights unspecified.
