5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
14 of 54
3.2 Technical Specification
PARAMETER SPECIFICATION
Downlink Frequency Range: 453.30-453.75MHz
Uplink Frequency Range: 458.30-458.75MHz
12.5kHz adjacent channel >20dBChannel Bandwidth selectivity:
25kHz adjacent channel >80dB
Number of Channels: 5
Number of ports: 2
RF Connectors: N type, female
Impedance: 50
VSWR: Better than 1.5:1
Sensitivity: 0.35 microvolts @ 12dB SINAD
Downlink Output Power:
Uplink Output Power:
10 Watts
Uplink TOI: 50dBm
Downlink TOI: 50dBm
RF level per carrier: >+23dBm
Passband ripple: <±1.5dB
Noise figure: <6dB (@max gain)
Gain: 96dB
Gain adjustment: 0-30dB (in 2dB steps)
In band spurious: Better than –36dBm
Spurious up to 3GHz: Better than –90dBc
Input AC Supply: 120V AC
Consumption: 150 Watts
Volt-free relay contacts
Excessive VSWRAlarms:
Forward power drop
MTBF: 80,000 Hrs.
Housing: 19” Rack mounted
