5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
13 of 54
3.1.3 Power Supply Shelf 50-060604 Parts List
19-000826 2U,3U,4U 19" UNIT 400 DEEP LID 1
19-001021 4U 19" UNIT 400 DEEP CHASSIS + BKT 1
19-001024 4U 19" UNIT FRONT PANEL FAB 1
20-001602 24V RELAY BOARD 1
80-064120 HEATSINK 4U FLATPAC 16A 10W 1
91-500025 3 PIN RIGHT ANGLE FREE PLUG NC-X 1
91-510003 3 PIN R.ANGLE FREE SOC.NC-X. 1
91-510004 3 PIN PNL.MOUNT SOCKET NC-X 3
91-520001 PWR MAINS INL FIXED/SOLD.TERMS 3
91-520004 POWER MAINS INL.FREE R/ANGLE 3
91-600001 'D'TYPE 9 WAY PLUG S/B TERM 1
92-340001 M3 x 8mm 'D'CONNECTOR SCREW LOCK 0
93-560001 VARISTOR V275LA20A 1
96-300054 24V 17A PSU 400W (XP BCC) 1
96-300056 48V 6A PSU DIN RAIL (TRACO) 1
96-700034 LED RED 5mm IP67 INTEGRAL RES. 24V 1
96-700035 LED GREEN 5mm IP67 INTEGRAL RES 24V 2
96-900018 AC TRIP SWITCH (5 AMP M.C.B.) 2
97-400002 HANDLE TYPE H6803 4U.[ALLOY] 2
