User Manual

5-Way Channelised UHF Cell Enhancer
Maintenance Handbook
H/book Number:-50-060601HBKM
Issue No:-
1
Date:-04/07/2003
Page:-
11 of 54
3. SPECIFICATION
3.1 5 Channel Channelised Cell Enhancer 50-060601 Parts Lists
AFL Part N. Description Qty.
50-060602 D/L CCE 80dB 10W Q108330 1
50-060603 U/L CCE 80dB 10W Q108330 1
50-060604 PSU Q108330 1
Modules described in the text are shown as highlighted in the parts list in the quantity
column. All fuses used in this equipment must be replaced with identical types as
proscribed in the description column of the particular unit’s parts list.
3.1.1 Downlink Channelised CE 50-060602 Parts List
02-010701 5P 380MHz(V.B/W)X CPLING SMA POSTS 2
05-002603 UHF 3dB SPLITTER SMA 2
05-003803 3 WAY SPLITTER, UHF, ZINGER 4
10-000701 1/4W0-30dB SWITCHED ATTENUATOR 1
11-007302 LNA. 380-500MHz 20dB (C/W RELAY) GA 2
11-007402 LNA. 380-500MHz 30dB (C/W RELAY) GA 1
12-001901 PWR AMP.450MHz 20W GEN.ASSY 1
12-002201 3 STAGE AMPLIFIER ALARM BOARD 2
12-002220 3 STAGE ALARM PCB COVER 2
13-001803 DUAL DC/DC CONVERTER 24V-12V 1A 1
17-003012 CHAN MOD 450MHz, 15kHz (8p) BW 5
19-000826 2U,3U,4U 19" UNIT 400 DEEP LID 1
20-001602 24V RELAY BOARD 1
80-024420 5U CHASSIS FRONT PANEL 1
80-024421 5U CHASSIS 400mm DEEP 1
80-043320 HEATSINK 1
91-020004 N JACK PANEL UT-141 3
91-500001 POWER PLG 3 PIN PNL.MOUNT NC-X 1
91-510003 3 PIN R.ANGLE FREE SOC.NC-X. 1
91-600001 'D'TYPE 9 WAY PLUG S/B TERM 1
91-620001 'D' 25 WAY SOCKET S/B TERM 2
91-620006 'D' 25 WAY CONNECTOR SHELL 2
91-700017 ICD 15 WAY 0.1' CONNECTOR 4
92-340001 M3 x 8mm 'D'CONNECTOR SCREW LOCK 0
96-110001 FUSE HOLDER 20 x 5mm6.3A 1
96-110013 T 3.15 A ANTI SURGE FUSE 20mm 1
96-500005 DC INPUT FILTERS 1
96-600002 INSULATING BOOT SMALL 1
96-600003 INSULATING BOOT D.C. 1
97-400006 5U HANDLE [ALLOY] 2
