15.7 Digital Outputs
AES/EBU/AES3, S/P-DIF, Optical (Toslink) active at the same time.
16/20/24 bit, 32kHz to 48kHz (System clock).
Output level: 2 to 5 volts
Output impedance: 110 Ohm
Clock output: 75 Ohm TTL.
15.8 System Clock
System clock internally 32kHz, 44.1kHz, 48kHz, 50ppm.
Frame clock out: BNC 75 Ohm TTL
Frame clock in: BNC 75 Ohm terminator switch, TTL 32kHz to 48kHz
15.9 Remotes
All channel remotes are isolated on relays and interfaced on 9 pin Sub-D connectors. More info: isolated
PhotoMOS Relays, Ron-max 12ohm, Imax=200mA, 24Vmax
15.10 Dimensions and Weight
Desktop layout: Width=260mm Height=85mm Depth=370mm
19”rack in/output unit: Width= 485mm Height=88.5mm Depth=300mm
Notes: 0dBu=775 mV.
All measurements were made on an
Audio Precision system Two.
For more info on this and many other broadcast consoles contact your nearest dealer or AXEL
TECHNOLOGY.
Axel Technology S.r.l
Via Caduti di Sabiuno 6/F
40011 Anzola dell’Emilia
Phone: [phone]
Fax: [phone]
Website: http://www.axeltechnology.it
Mail to: [e-mail]
Axel Technology reserves the right to change these specs at any time, due to new product improvements
and new components.
