Local Function Audio On/Off enables you to disable the audio function of the On switch. This way you can
use the On switch only to trigger the remote.
Trigger On Remote causes a trigger when the channel is enabled by On switch. Trigger Off
remote causes a trigger when the channel is disabled by the On switch.
Note:
When the audio function is disabled you will get a retrigger signal when
pressing the ON switch regardless the settings for trigger On/Off remote.
Action
Latching means that the On switch holds its state until pressed again. Momentary means
that the On switch changes state again at the moment of release.
Remote Buss
Here you can select if the ON switch must activate a remote Buss (1..4)
CUE Switch
Local Function
Same for On switch => Function
Action
Same for CUE switch => Action
Remote Buss
Here you can select if the CUE switch must activate a remote Buss (1..4)
Fader
Local Function
With the Trigger On/Off remote option you can select if you want a trigger when the
fader opens, fader closes, fader opens and closes and fader closes.
Remote Buss
Here you can select if the fader must activate a remote Buss (1..4)
Cobranet
Local Function
Determines how the incoming cobranet remote must be treaded. NOTE: Because the
cobranet remote always is continuous at least one option must be marked for the
cobranet remote to be passed on. When no options are marked the remote will not be
passed through.
Remote Buss
Here you can select if the incoming cobranet remote must activate a remote Buss (1..4)
Input Active Generates
Redlight1..2
Option to activate Redlight 1..2 when input goes on air.
CRM Mute
Option to mute CRM when input goes on air.
Studio Mute
Option to mute Studio output when input goes on air.
Total CUE Reset
Option to do a total CUE reset when input goes on air.
Local CUE Reset
Option to do a local CUE reset when input goes on air.
