User manual

LCD screen
Size
Display proportion
Type
Pixel distance
View angle
15.0 (diagonal)
304.1 mm(H)X228.0 mm(V)
TFT color
0.297 mm(H)X0.297mm( V)
80(L)/80(R)/80(T)/55(B)
Frequency
Hor scanning frequency
Ver scanning frequency
Display color
30 kHz 75 kHz
50 Hz 75 Hz
16.7M color
Display mode
Recommended mode
Max mode
1024X768@75 Hz
Input signal
Synchronous signal
Video signal
H/V separation, TTL positive/negative
H/V composite, TTL positive/negative
Green synchronous, 0.3Vp p,negative
0.7 Vp p@75ohm
TV/Video
Image system
Audio system
Video form
PAL/SECAM/NTSC(In video mode)
DK/I/BG/L
CVBS
Power
Adapter input
~ 100V-240V (50 /60 Hz)
Unit/net weight LXWXH
438.7mmX163.1mmX295.7mm/7.0kg
Environmental
factor
Working temperature
Working humidity
Storing temperature
Storing humidity
10% 80%~
5% 95%~
Audio parameter
Audio input
Frequency response
3.5 jack(L,R), 0.5 0.3 Vrms
TV signal: 100 Hz 12 kHz(-3dB)~
AV: 100 Hz 15 kHz (-3dB)~
5 35 ~
C
C
-20 45~
C
C
~
~
-
Disc type
DVD VIDEO
MPEG4
*
SVCD
**
VCD1.0, 1.1, 2.0 version;
CD-DA
Output
Analog audio output, coaxial digital audio
Output, composite video output
DVD
-
S-VHS, RGB, YPbPr, VGA
Hint: the items with " " symbol are related to LCD screen. Specifications and design are subject
o change without notice.
Some discs labelled with MPEG 4 on the market actually are * .rm/* .ram/* .rmm and others which
are not compatible. Please take care when buying discs.
This unit cannot play some SVCD discs with VCD format.
**
Because of disc quality and format difference, we cannot make sure smoothly read all discs; some
functions cannot be fulfilled for the disc speciality, but not machine trouble.
*
SPECIFICATIONS
Supply
50
As for weight and size, please take actual object as standard.
Panel Life
Hours
50,000
Adapter output
12V/4.5A
_
___
DVB
Input connector
R Loop through output connector
F
Frequency range (VHF/UHF)
IEC-Type, IEC 169-2, Female
Channel range(VHF/UHF)
IEC-Type, IEC 169-2, Male (loop throughout)
174MHz 858MHz
~
7 & 8 Mhz
