TFT-LCD TV W152D USER MANUAL READ CAREFULLY BEFORE OPERATION
IMPORTANT SAFETY INSTRUCTIONS TO PREVENT ELECTRICAL SHOCK. CAUTION DO NOT REMOVE THIS COVER. NO RISK OF ELECTRIC SHOCK. DO NOT OPEN. REFER SERVICING TO QUALIFIED USER- SERVICEABLE PARTS INSIDE. SERVICE PERSONNEL. This symbol indicates dangerous voltage inside the product that presents a risk of electric shock or personal injury. This symbol indicates important instructions accompanying the product. Please read this manual carefully before using this product.
IMPORTANT SAFETY INSTRUCTIONS Do not expose the LCD TV/monitor to extreme temperature conditions or to extreme humidity conditions. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. Do not place the LCD TV/monitor on an unstable cart, stand, tripod, bracket, table, or floor where it can fall. It is damaged if dropped, hit or scratched. Do not clean the front with keton-type materials (e.g.
CONTENT INSTALLATION Normal installation 1 PANEL BUTTON FUNCTIONS Front panel Right panel 2 3 Left panel Rear panel 2 3 Battery installation 7 EXTERNAL EQUIPMENT Connecting figure 4 REMOTE CONTROLLER Remote buttons 5 LET'S START Change source operation 8 TV MENU SETUP 9 11 14 Sound 10 System setting 13 15 Page selection Lock Zoom in teletext Colorized buttons 15 15 16 16 18 20 Sound Function 19 21 Brief introduction 22 Function introduction 22 Comparison between DVD and other di
CONTENT DVD OPERATION 26 Direct play 27 Memory 27 Select track to play directly by number button 28 Select language/audio 28 Repeat playback 29 Repeat playback of selected segment 29 Fast playback 30 Play from the desired position 30 Zooming the displayed frame 31 MPEG4 and JPEG file playback 34 Speaker setup 35 Video setup 36 VCD, SVCD menu playback DVD FUNCTION SETUP General setup Audio setup 35 35 Initial setup 36 CARD READER AND USB OPERATION Usage of USB equipment and 3-IN
INSTALLATION NORMAL INSTALLATION C A B Ostium Kickstand M5 28 Screw 1pcs Rear viewing of LCD TV 1, Hook the tache (labeled A)of the kickstand on to the slot (labeled C) 2, Tighten the screws ( M5 28) through the ostium (labeled B). 3, Figure 1 shows the finished installation.
PANEL BUTTON FUNCTIONS FRONT PANEL HD3DSound Indicator(the indicator is red when in standby mode, and green when in working normally) IR sensor window LEFT PANEL MENU(Enter or exit TV menu) CHANNEL(Increase or decrease channel number) VOLUME(Increase or decrease volume) SOURCE(Select input source ) STANDBY(To switch in standby mode and power-on mode.
PANEL BUTTON FUNCTIONS RIGHT PANEL USB jack MEDIA CARD socket EJECT button STOP button PLAY/PAUSE button HEADPHONE jack REAR PANEL 8 9 1 YPbPr or YCbCr input terminal 2 Composite video/audio and S-VIDEO audio input 3 PC audio and YPbPr audio input 4 Coaxial digital audio output 5 S-VIDEO input 6 SCART connecting terminal 7 RF input terminal 8 VGA input terminal 9 12V DC input terminal 7 r b 1 r b 2 3 4 5 6 3
EXTERNAL EQUIPMENT CONNECTING DIAGRAM L R DVD or VCR player Power amplifier (with coaxial digital audio in) NOTE You should insert all interconnecting cables BEFORE plugging in the power cord.
REMOTE CONTROLLER REMOTE BUTTONS 1 EJECT Disc in/out, valid in DVD mode. 2 [ ] button Pause playing/steps playback in pause mode, valid while in DVD mode. 1 3 [ ] button 2 To fast-forwards DVD playback, valid in DVD 3 mode. 4 ] button 4 [ 1 2 3 To select the next chapter or track. 5 4 6 5 5 Number button 7 8 9 To select program number. 0 6 6 RETURN To exchange channel between the previous 7 program and the current program, valid in TV 8 or DVB mode.
REMOTE CONTROLLER 22 23 24 25 26 27 28 STANDBY To switch between standby mode and power-on mode. [ ] button To fast backward playback, valid in DVD mode. [ ] button To select the previous chapter or track, valid in DVD mode. [ ] button To stop playing, valid in DVD mode. TWO-DIGIT NUMBER BUTTON To switch between one or two-digit program number. SOURCE To select input source: TV, DVB, DVD,AV, S-VIDEO,SCART, YPB P R and VGA.
REMOTE CONTROLLER BATTERY INSTALLATION Remove the battery cover. Insert two SUM-4(AAA) batteries matching the -/+ polarities of the battery to the -/+ marks inside the battery compartment, as follows: BATTERY LIFE Generally speaking, the battery may be used for one year, but the battery life is also related to the usage times and remote controller operation. If the remote controller is still invalid when very near to the remote sensor window, please replace the battery. Please use SUM-4(AAA) battery.
LET'S START After this unit is well fixed on the desk or on the wall, and the cords are well connected for input or output, what you should do next is: First, connect the adapter to the LCD TV, then the unit will go into standby mode, and you can see the indicator goes into red. Second, press [STANDBY] key on the left side of the LCD TV or [STANDBY] button on the remote control to make the unit switch into working mode, and you will see the indicator turn green.
TV MENU SETUP This product can store up to 100-channel programs (0 99). You can select your favorite channel through [CH+/-] or number buttons, and you can scan and store all of the channels through manual or automatic mode.
TV MENU SETUP SOUND Press [ ] select " " and press [ ] or [OK] button to enter the following section: SOUND SOUND USER BALANCE 40 BASS 50 34 TREBLE OFF BBE VIVA SELECT ENTER OK Press [ ] button to select item and press [ item description. Item RETURN SETUP ] button to adjust . The following is sound Description SOUND Can be change between " USER " , "STANDARD","NEWS " , " FILM " and " MUSIC " . BALANCE To adjust balance of left and right channels. BASS To adjust bass.
TV MENU SETUP TV SETTING press [ ] select " " item and press [ ] or [OK] button to enter the following section: TV SETTING CHANNEL 5 CHANNEL EDIT FINE TUNE 168.90MHZ MANUAL SEARCH AUTO SEARCH SELECT Press [ ENTER ] button to select item and press [ Item OK RETURN SETUP ] button to adjust or activate. Description CHANNEL To change the channel number. CHANNEL EDIT To enter a submenu to set channel skip and channel swap. Please refer the next page.
TV MENU SETUP CHANNEL EDIT 5 CHANNEL SKIP NO SWAP __ ? OK Item Description CHANNEL To select current channel here. SKIP To select "Yes " or "No ", you can select "Yes " to make current channel unaccessible while using [CH+/-] button to browse channels. SWAP Select or enter the channel number directly to swap with current channel. OK Highlight this option and press the [OK] button to confirm the swap function.
TV MENU SETUP SYSTEM SETTING You can setup some system configuration here. Press [ ] to select " " item and press [ ] or [OK] button to enter the following section: SYSTEM SETTING COLOR SYSTEM AUTO I SOUND SYSTEM ENGLISH LANGUAGE OFF TRANSPARENCY RESET SELECT Press [ ENTER OK ] button to select item and press [ Item COLOR SYSTEM RETURN SETUP ] button to adjust or activate. Description Can be changed between: "Auto", "PAL" and "SECAM".
TV MENU SETUP NICAM/BILINGUAL RECEIVING If you can receive Nicam/bilingual signal, you can operate as follows to enjoy that. You can select Nicam stereo, mono channel or bilingual through NICAM button on the remote control. If stereo signal is too weak, this unit will switch into mono channel automatically.
15
TELETEXT FUNCTION ZOOM IN TELETEXT When teletext page shows, you may double zoom in to display this teletext page; Press [SIZE] button to zoom in the upper half part of teletext page; Press [SIZE] button again to enter the under half part of teletext page; Press this button for the third time to return to original display mode. DISPLAY MODE Press [REVEAL] button to display the hidden teletext information. Press this button again to cancel teletext information displaying.
AV, S-VIDEO, SCART AND YP B P R SETUP VIDEO SETTING MENU When in AV/ S-VIDEO/SCART input mode, there are 6 color system modes for selection: "Auto", "PAL"," N 3.58", "N 4.43", "PAL60" and "SECAM". Select the right system for your video program. If you do not know which mode your video playback devices and video media is using, you should select the auto mode or you should check and confirm this with your supplier.
VGA SETUP With the VGA mode supported up to 1024*768@75Hz, and speakers built in, you can use this unit as a multimedia PC monitor. When this unit works in VGA mode, the following setup can be done. Press [SETUP] button to enter main section. Press [ ] button to select sections and then press [ ] button or [OK] button to enter. If all is done, please press [SETUP] button twice to exit and your setup data will be saved automatically.
VGA SETUP Here shows the color temperature sub menu. COLOR TEMPERATURE USER COLOR Press [ RED 50 GREEN 50 BLUE 50 ] button to select item and press [ ] button to change and adjust value of item. Description Item COLOR Select color temperature mode :"User", "C6500", "C8700", "C9300".
VGA SETUP MONITOR SETTING Press [ ] button to select " " and press [ ] or [OK] button to enter. MONITOR SETTING PHASE 49 FREQUENCY 50 H-POSITION 50 V-POSITION 50 SELECT Press [ ENTER ] button to select item and press [ OK RETURN SETUP ] button to adjust value of item. Description Item PHASE To adjust phase.
VGA SETUP FUNCTION Press [ ] button to select " ", and press [ ] or [OK] button to enter. FUNCTION OSD H-POS 50 OSD V-POS 50 ENGLISH LANGUAGE TRANSPARENCY OFF RESET SELECT Press [ ENTER OK RETURN SETUP ] button to adjust value of item. Description Item OSD H-POS To adjust the horizontal position of OSD OSD V-POS To adjust the vertical position of OSD LANGUAGE Select OSD language [English] TRANSPARENCY To adjust transparency of OSD.
DVD OPERATION DVD OPERATION Brief Introduction DVD provides brand-new AV effect for consumers with its extraordinarily large capacity and outstanding audio-video effects. Its capacity is as high as 4.7-17 GB (approximately 7-26 times the CD capacity) and horizontal resolution of picture is above 500-line. Comparison Between DVD and Other Discs DVD Recording Method Capacity Playback Time LD Digital/MPEG2 Single- Single- sided 1 layer 4.7G sided sided 2 layers 1 layer 9.4G 8.
DVD OPERATION TV Screen Disc Pictures 4:3 16:9 Pan-Scan Letterbox 4:3 16:9 Features This player employs the new generation MTK decode chip with more convenient system and more stable operation. Super error correction slot-in loader with twin laser with good shockproof performance. Brand-new AV Effects 1 Compatible with MPEG 4 format discs to produce wonderful pictures. 2 108MHz/12bit video DAC with more vivid and brilliant pictures.
DVD OPERATION 2 Multi-level zoom in/out playback function to provide you with brand-new enjoying way. 3 Multiple aspect ratios to fit TV sets of various screen ratios. 4 Parental lock function to prevent children from watching unsuitable discs. 5 Multiple dubbing languages and subtitle languages bring you the best entertainment status all the time. Super compatible with VCD, SVCD, CD, HDCD, KODAK PICTURE CD etc. NOTE: * Some discs labelled with MPEG4 on the market actually are *.rm/*.ra/*.ram/*.
DVD OPERATION PLAYBACK DVD MPEG4 SVCD VCD CD 1. Power on and switch signal source to DVD mode and the unit begins to work. 2. Place the disc (with label side facing users) to the door and the unit will draw in the disc automatically. The unit begins to read disc information. STANDBY EJECT PLAY STOP 3. Press [PLAY] button to begin playing disc. When the unit playing a disc, press[ ] button the firs time and the unit enters pause state, while press [ ] button again and the unit resumes playback. 4.
DVD OPERATION VCD, SVCD MENU PLAYBACK SVCD VCD When playing SVCD, VCD2.0 discs with menu playback function, you may enjoy simple menu playback alternation function. You may set menu playback state in the setup menu and select menu playback or sequence playback. For instance, VCD 2.0 disc menu playback. 1. TV screen displays main menu. 1. 2. Press number buttons to select. For instance, press number button 1 to select main menu 1. 1. 2. 2. After entering main menu 1, TV screen displays submenu. 1. 2. 3.
DVD OPERATION DIRECT PLAY Direct play is a creative function that very helpful for users to enjoy DVDs. With direct play function, you can play DVD directly, skipping the legal warning, advertisements, chapter selection and other thing that come before the movies start. You can enjoy pure movies without bothering. When the disc is loaded and the legal warning, advertisements, chapter selection message shows, just press [ ] button to activate direct play function and start a pure movies playback.
DVD OPERATION SELECT TRACK TO PLAY DIRECTLY BY NUMBER BUTTONS SVCD DVD VCD CD 1. Insert disc, after disc reading and normal playback, press number buttons to select track to play directly. If track number is less than 10, press number buttons 1 to 9 to directly select. For instance, select the seventh track: 7 If track number is more than or equal to 10, press [-/- -] button and then number buttons 0 to 9.
DVD OPERATION REPEAT PLAYBACK DVD MPEG4 SVCD CD VCD The repeat playback function enables a certain title/chapter/track/disc repeated. 1. Press [REPEAT] button. Each press of REPEAT button may realize different repeat functions. DVD DISC: Title Chapter ALL Repeat Off SVCD, VCD, CD discs: To SVCD, VCD2.0 discs, the repeat function is effective in sequence playback mode; to VCD1.1, CD discs, the repeat function may be directly operated. Track ALL Repeat Off To SVCD, VCD2.
DVD OPERATION FAST PLAYBACK MPEG4 DVD SVCD VCD CD When playing discs, you may select fast forward or fast backward playback to search a certain point. 1. Press [ ] button and the unit begins fast forward playback. Press [ ] button each time and the disc playback speed switches in the following sequence circularly: 2X 4X 8X 32X 16X 2. Press [ ] button and the unit begins fast backward playback.
DVD OPERATION Play MPEG4 disc 1. Select track Press [GOTO] button until TV screen displays the following figure. Then press number buttons to input the track. Select 2. Search track time Press [GOTO] button until TV screen displays the following figure. Then press number buttons to input hour, minute and second. -:--:-- Play SVCD, VCD and CD discs 1. Search disc time Press [GOTO] button until TV screen displays the following figure. Then press number buttons to input minute and second.
DVD OPERATION MPEG4 AND JPEG FILE PLAYING MPEG4 is the audio standard published by MPEG(Moving Pictures Experts Group) in November, 1998. As the discrepant parts between frames of picture are only processed and the same parts are deleted, the data number are greatly decreased. The most distinct feature of MPEG4 is the high compression and clear imaging. Furthermore, MPEG4 provides elastic specifications to adjust the stream according to the used requirements.
DVD OPERATION 1. Play MPEG4 file After you put an MPEG4 format file into the unit, it will search disc information and display the operation menu as figure A (The displayed content varies with disc.). A: B: 00:00 00:00 001/004 00:00 00:00 001/369 \Du000\ \ .. Du000 Press [ Du001 A/V MP000 Du002 A/V MP001 Du003 A/V MP002 ] button to select the directory you desired and press [OK] button to confirm.
DVD OPERATION 4. When playing JPEG file, pressing [ ] button may realize preview playback function. At the same time, all JPEG files are displayed on TV screen. One frame can display up to 12 pictures at most. The rest ones are shown on the next frame. Pressing [ ] button may enter the next frame and [ ] button may enter the previous frame. You may press number buttons or [ ] button to select the picture you desired and press [OK] button to confirm. 5.
DVD FUNCTION SETUP VIDEO SETUP Video Setup Page Sharpness Brightness Contrast Hue Saturation Gamma Low 00 00 00 00 Off Go To Video Setup Page 1. Sharpness: this item is used to set the sharpness of video outputs. Optional settings: High, Medium, Low; Default: Low 2. Brightness: this item is used to set the brightness of video outputs. 3. Contrast: this item is used to set the contrast of video outputs. 4. Hue: this item is used to set the hue of video outputs. 5.
DVD FUNCTION SETUP NOTE Audio, subtitle and disc menu language are only effective to DVD disc. If the disc is not recorded with the language you appointed, the unit will apply the language that the disc appointed to play. Select other languages: press [ ] button to move cursor to "OTHER" item, press [OK] button and then number buttons to input the language code you desired. After input finishes, press [OK] button again. 6.
CARD READER AND USB OPERATION USAGE OF USB EQUIPMENT AND 3 -IN-1 CARD READER USB refers to Universal Serial Bus. Most of USB devices on the market are USB1.1 or USB2.0. There are some types USB 1.1 devices: Monitors Communication devices Audio Human Input Device(HID) Mass storage. Most flash memory ,USB HDD ect. belongs to Mass Storage Class . Mass Storage Class includes 2 transport manners: 1. USB 1.1 Mass Storage Class Control/Bulk/Interrupt (CBI) Transport 2. USB 1.
TIME SETTINGS TIME SETTING At any display mode you press [TIMER] button, calendar will show on the screen, CALENDAR 2005-04-03 SUN MON 12:13:35 TUE WED THU FRI SAT 4 5 6 7 8 14 15 1 2 3 9 10 11 12 16 17 18 19 20 21 22 23 24 25 26 27 28 29 13 30 SET TIME SET TIMER ON SET TIMER OFF Item Description SET TIME Press [ /OK] button to go to the set time sub menu. SET TIMER ON Press [ /OK] button to go to the set timer on sub menu.
TIME SETTINGS HOUR 2 and MINUTE 2 set for the TIMER 2 for auto power on ,ACTIVATE 2 can be set for activate setting for TIMER 2. You can choose ON/OFF and ONCE on ACTIVATE 2. When ON is selected, timer 2 will always enable auto powering on . When you select OFF ,timer function will be disable .If you select "ONCE", timer 2 will enable auto powering on and, after it powers on automatically for the first time, the setting will go to "OFF" automatically.
DVB OPERATION Power on and switch signal source to DVB mode and the unit begins to work. Press the [DVB MENU] button, the Main Menu will be displayed, in which you can set your preferences, Search for channels, edit the channels list or your favourite list , viewing Programme Guide Information, etc. It is easy to see that the Main Menu is composed of six parts: General Setting, Advanced Setting, Auto Search, Manual Search, Channel Setting, EPG.
DVB OPERATION Choose OFF to shut off the Antenna power ,if you have a passive or a self powered active ANTENNA . Warning: You should never shortcut the antenna jack, it may cause injury or damage some unit. The receiver is only able to supply DC 5V/50mA(MAX), never connect heavy load to the receiver, it may cause damage. ADVANCED SETTING You can set parental control for each programme . You can also change your password.
DVB OPERATION Note: The Default Password is "000000". If you have forgotten your Password, please contact your local product distributor. Clear Channels If you just want to delete the Channel List, select the Clear Channels item. 1. Select the Clear Channels item using the[ ] or press [OK] button. 2. A prompting message will be displayed to request your confirm, select YES and press the [OK] button to confirm. 3. Select NO or press the [DVB MENU] button to return if you want to abort.
DVB OPERATION MANUAL SEARCH You can search channels manually by searching parameters. Note: Select different item using the[ ]button, Press the[ ]button to do your setting. Press the [DVB MENU] button to save the changes and return to the previous menu. Channel Select your desired frequency channel to search using the [ ] button. When entering frequency channel value, the appropriate frequency value is entered.
DVB OPERATION After finishing all the setting above ,select the Search item to start searching. The searching result will be displayed in the Search Result window. Note: If you press the [DVB MENU] button during searching, the operation is stopped and the channels found until then will be saved. If search operation is successfully completed, and the channel does not exist, try to reset the search operation again if necessary. CHANNEL SETTING This chapter describes how to edit channels.
DVB OPERATION Channel Sort You can sort all TV or Radio channel lists by channel ,name or free/scrambled. Note: Select the different sort ways using the [ Ascending Sort ]button, then press [OK] button to confirm. Channel lists are sorted by channel name from A to Z. Descending Sort Channel lists are sorted by channel name from Z to A. Free First Free channels will be placed on the top of the list. Scrambled First Scrambled channels will be placed on the top of the list.
TROUBLESHOOTING Please check for causes of problems in accordance with the following chart before contacting any maintenance personnel.
TROUBLESHOOTING DVD TROUBLESHOOTING Causes Symptom Correction Not play 1. Condensation on laser head 2. Disc not properly loaded 3. Disc not compatible with the unit 1. Switch on power and wait for 1 to 2 hours 2. Make sure label side of the disc facing up 3. Confirm whether this unit compatible with the placed disc 1. Too large volume of connected device 2. Sound field mode not suitable for disc 1. Adjust the device volume Sound distortion No sound No image No color 1. Disc warped or dirty 1.
SPECIFICATIONS LCD screen Size Display proportion Type Pixel distance View angle 15.0 (diagonal) 304.1 mm(H)X228.0 mm(V) TFT color 0.297 mm(H)X0.297mm( V) 80(L)/80(R)/80(T)/55(B) Hor scanning frequency Ver scanning frequency Display color Recommended mode Display mode Max mode Frequency Panel Life 30 kHz~ 75 kHz 50 Hz~ 75 Hz 16.
DISPLAY MODE SUPPORTED PC INPUT MODE Resolution Hor scanning frequency Ver scanning frequency (KHz) (Hz ) Pixel frequency (MHz) Format 640 350 31.5 70.0 25.17 DOS 720 400 31.5 70.0 28.32 DOS 640 480 31.5 60.0 25.18 DOS 640 480 37.9 72.0 31.50 VESA 640 480 37.5 75.0 31.50 VESA 800 600 35.1 56.2 36.00 VESA 800 600 37.9 60.0 40.00 VESA 800 600 48.1 72.0 50.00 VESA 800 600 46.9 75.0 49.50 VESA 1024 768 48.4 60.0 65.00 VESA 1024 768 56.5 70.
DISPLAY MODE SUPPORTED VIDEO INPUT MODE Format Hor scanning frequency Ver scanning frequency Vert scan type 720X480 31.47 59.94 480P 720X480 15.734 59.94 480i 720X576 31.25 50 576P 720X576 15.625 50 576i NOTE Specifications and design are subject to change without notice.
ACCESSORIES Please check the following accessories. Operational Manual 1 8 5 2 6 3 9 4 0 7 User manual Coaxial digital audio cord Remote control and battery Power adaptor Wall Mount Holder Kit AK556(optional) Audio cord Wall Mount Holder Kit AK558(optional) AV cord Kickstand Kit 5195201 V0.
