TFT-LCD TV W152D USER MANUAL READ CAREFULLY BEFORE OPERATION W152D
IMPORTANT SAFETY INSTRUCTIONS TO PREVENT ELECTRICAL SHOCK. CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. DO NOT REMOVE THIS COVER. NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates dangerous voltage inside the product that presents a risk of electric shock or personal injury. This symbol indicates important instructions accompanying the product. Please read this manual carefully before using this product.
IMPORTANT SAFETY INSTRUCTIONS Do not clean the front with keton-type materials (e.g.Acetone ),ethyl alcohol, toluene, ethy lacid, methyl, or chloride-these may damage the panel. Locate your DC adapter near an easily accessible AC outlet. If your LCD TV does not operate normally in particular, if there are any unusual sounds or smells coming from it unplug it immediately and contact an authorized dealer or service center. High temperature can cause problems.
CONTENT INSTALLATION Normal installation 1 PANEL BUTTON FUNCTIONS Panel control 2 Rear panel 3 Battery installation 7 EXTERNAL EQUIPMENT Connecting diagram 4 REMOTE CONTROL HANDSET Remote buttons 5 LET'S START Changing source operation 8 TV MENU SETUP Picture TV setup 9 12 Sound 11 Function 14 15 Page selection Lock Zoom in teletext Colorized buttons 15 15 16 16 TELETEXT FUNCTION Teletext display Mix mode Index Display mode 15 15 16 AV, SCART and YPB P R SETUP Video setting menu 17
CONTENT DVD OPERATION 24 Features 25 Compatible disc types 26 Playback 27 Volume control 27 Play/pause playback 28 Information 28 DVD menu playback 28 Brief introduction to DVD VCD, SVCD menu playback 29 PBC playback 30 Direct play 30 Memory 31 Select track to play directly by number buttons 31 Select language/audio 31 Repeat playback 32 Repeat playback of selected segment 33 Fast playback 33 Play from the desired position 34 Zooming the displayed frame 35 MPEG4 and JPE
INSTALLATION NORMAL INSTALLATION C A B Hook Ostium M4 10 Screw 1pcs Kickstand Rear viewing of LCD TV 1, Hook the tache (labeled A)of the kickstand onto the plate (labeled C). 2, Tighten the screws ( M4 10) through the ostium (labeled B). 3, Figure 1 shows the finished installation. The kickstand can rotate 15 -degree.
PANEL BUTTON FUNCTIONS PANEL CONTROL 10 11 12 13 14 3 4 5 6 7 15 16 8 9 1 2 Front panel 1 IR sensor window 2 Indicator( Indicator is red when in standby mode, green when working normally. ) Left panel 3 SETUP (Enter or exit setup menu) 4 VOL+/-(Increase or decrease volume) 5 CH+/- (Increase or decrease channel number) 6 SOURCE (Enter to exit source menu) 7 STANDBY (To switch between standby mode and power-on mode) 8 Headphone jack 9 POWER(Turns on or off the power supply).
EXTERNAL EQUIPMENT CONNECTING DIAGRAM PC IN VGA AUDIO FM ANTENNA COAXIAL Y PB/CB SCART PR/CR VIDEO L R AV IN R F cable L R DVD or VCR player Power amplifier (with coaxial digital audio in) NOTE You should connect all interconnecting cables BEFORE plugging in the power cord.
REMOTE CONTROLLER REMOTE BUTTONS 1 EJECT Disc in/out in DVD mode. [ ] button To play normally or pause playing in DVD mode. 2 1 2 3 2 3 4 5 6 7 8 9 1 0 SLEEP 3 [ ] button To fast-forwards DVD playback in DVD mode. 4 4 [ ] button To select the next chapter or track in DVD mode. 5 5 Number button To select program number. 6 6 RETURN To exchange channel between the previous program and the current program in TV/DVB/ FM mode. SLEEP To set the sleep timer.
REMOTE CONTROLLER 22 STANDBY To switch between standby mode and poweron mode. 23 [ ] button To fast backward playback in DVD mode. 24 [ ] button To select the previous chapter or track in DVD mode. 25 [ ] button To stop playing in DVD mode. 22 23 26 TWO-DIGIT NUMBER BUTTON To switch between one or two-digit program number. 27 SOURCE To select input source: TV, DVB, DVD, FM, AV, SCART, YPB P R and VGA. 28 UP/DOWN cursor To select upward/downward in the menu or change the channel in TV/DVB mode.
REMOTE CONTROLLER BATTERY INSTALLATION Remove the battery cover. Insert two SUM-4(AAA) batteries matching the -/+ polarities of the battery to the -/+ marks inside the battery compartment, as in the following figure: BATTERY LIFE Generally speaking, the battery may be used for one year, but the battery life is also related to the usage times and remote controller operation. If the remote controller is still not operating when very near to the remote sensor window, please replace the battery.
LET'S START After this unit is well fixed on the desk or on the wall, and the cords are well connected for input and output, what you should do next is: Firstly, connect the adapter to the LCD TV, and turn on the power switch then the unit will go into standby mode, you can see the indicator turn red. Secondly, press [STANDBY] key on the left side of the LCD TV or [STANDBY] button on the remote control to make the unit switch into working mode, and you will see the indicator turns green.
TV MENU SETUP This product can store up to 100-channel programs (0 99). You can scan and store all of the channels through manual or automatic scan mode. In TV mode, press [SETUP] button and the setup menu will show as follows: Pressing [ ] button on the remote control, PICTURE you can select setup menu sections(setup menu consist of " PICTURE " , " SOUND " , " TV PICTURE MODE SETUP " , " FUNCTION ") .
TV MENU SETUP NOTE " " Means there are more items in this page, you can press [ ] button to select them. Select "BRIGHTNESS " to adjust it, the sub item will show as follows : press [ ] button to adjust the value of brightness.
TV MENU SETUP SOUND Select " "and menu will show as follows: SOUND SOUND MODE USER BALANCE 50 BASS 50 50 TREBLE NICAM SELECT MONO OK ENTER SETUP RETURN Press [ ] button to select different items and press [ following are the descriptions of the sound item. Item ] button to adjust them. The Description SOUND MODE Can be changed between " USER " , "MUSIC" , " FILM " and "NEWS" . BALANCE To adjust balance of left and right channels. BASS To adjust bass. TREBLE To adjust treble.
TV MENU SETUP TV SETUP Select " " and TV setup menu will show as follows: TV SETUP CHANNEL TV SETUP SOUND SYSTEM 1 SOUND SYSTEM I AUTO SEARCH MANUAL SEARCH 40.00MHZ FINE TUNING CHANNEL EDIT AUTO SEARCH SELECT Press [ OK I 40.00MHZ FINE TUNING AUTO COLOR SYSTEM ENTER SETUP RETURN SELECT ] button to select different items and press [ ADJUST SETUP RETURN ] button to adjust them. Description Item CHANNEL To change the channel number.
TV MENU SETUP Select "AUTO SEARCH " , the searching menu will show as follows: AUTO SEARCH 3 FOUND: 3 1 VHF L 2 112.25MHZ SETUP RETURN 4 1 The number of programs have found. 2 The current searching frequency Band, 3 Bands in total: "VHF L" ,"VHF H"," UHF". 3 The current searching frequency. 4 During the searching, you can press [SETUP] button to stop it.
TV MENU SETUP FUNCTION You can setup system configuration here. Press [ ] to select " " item and press [ ] button to enter the following section: FUNCTION LANGUAGE ENGLISH TRANSPARENCY LEVEL 3 OFF SLEEP RESET SELECT Press [ OK ENTER SETUP ] button to select different items and press [ Item RETURN ] button to adjust them. Description LANGUAGE Set OSD language. TRANSPARENCY To adjust transparency of OSD. it can be change from OFF to LEVEL6, 7 levels in total.
15
TELETEXT FUNCTION ZOOM IN TELETEXT When teletext page shows, you may double zoom in to display this teletext page; Press [SIZE] button to zoom in the upper half part of teletext page; Press [SIZE] button again to enter the under half part of teletext page; Press this button for the third time to return to original display mode. DISPLAY MODE Press [REVEAL] button to display the hidden teletext information. Press this button again to cancel teletext information displaying.
AV ,SCART and YP B P R SETUP VIDEO SETTING MENU The menu setup of AV/SCART /YPB P R modes is much the same as that of TV mode, except the " " section is invalid and a bit difference in sound mode. It is not repeated here. You can find it in preceding pages. NOTE If no signal input in TV, AV, SCART, YPB P R the screen will show a similar signal to the following figure. This unit will go into standby mode automatically with no signal input for 5 minutes.
VGA SETUP With the VGA mode supported up to 1024*768@75Hz, and speakers built in, you can use this unit as a multimedia PC monitor. When this unit works in VGA mode, the following setup can be done. Press [SETUP] button to enter main section. Press [ ] button to select sections and then press [ ] button or [OK] button to enter. If all is done, please press [SETUP] button twice to exit and your setup data will be saved automatically.
VGA SETUP Here shows the color temperature sub menu. COLOR TEMPERATURE COLOR TEMP. NORMAL RED 50 GREEN 50 BLUE 50 ADJUST SELECT Press [ ] button to select item and press [ SETUP RETURN ] button to adjust the value of the item. Description Item COLOR TEMP. Select color temperature mode :"USER", "NORMAL", "WARM" and "COOL". RED Adjust red value of color temperature. GREEN Adjust green value of color temperature. BLUE Adjust blue value of color temperature.
VGA SETUP MONITOR SETUP Press [ ] button to select " " and press [ /OK] button to enter. MONITOR SETUP PHASE 50 FREQUENCY 50 H-POSITION 50 V-POSITION 50 SELECT Press [ OK ENTER SETUP RETURN ] button to select different items and press [ Item ] button to adjust . Description PHASE To adjust phase. FREQUENCY To adjust frequency. H-POSITION To adjust screen horizontal position. V-POSITION To adjust screen vertical position.
VGA SETUP FUNCTION Press [ ] button to select " ", and press [ /OK] button to enter. FUNCTION LANGUAGE ENGLISH TRANSPARENCY LEVEL 3 OFF SLEEP RESET SELECT Press [ OK ENTER SETUP ] button to select different items and press [ RETURN ] button to adjust . Description Item LANGUAGE Select OSD language . TRANSPARENCY To adjust transparency of OSD. it can be change from OFF to LEVEL6, 7 levels in total. SLEEP To set the sleep timer.
FM OPERATION FM With radio decoder built in , you can enjoy radio programs using this unit. Connect the FM antenna in the accessories to the FM socket on the rear panel of the TV, change source to FM. Press [SETUP] button and a menu will show as follows: FM CHANNEL 12 FREQUENCY 101.20MHz MANUAL SEARCH AUTO SEARCH SELECT OK ENTER SETUP RETURN 1. CHANNEL: Display current channel number, press [ ] button to change channel. 2.
FM OPERATION SOUND In main section press [ ] button to select " ", press [ /OK] button to enter. SOUND SOUND USER SOUND MODE BALANCE 40 BASS 50 TREBLE 34 MTS SELECT MONO OK ENTER SETUP RETURN The operation of sound options here is the same as that in TV mode. Please refer to P11. FUNCTION Press [ ] button to select " " and press [ /OK] button to enter.
DVD OPERATION Brief Introduction to DVD DVD is well known for its extraordinarily large capacity and outstanding audio-video effects. Its capacity is as high as 4.7-17 GB (approximately 7-26 times the CD capacity).With 500-line horizontal resolution of picture , it brings a new era to household AV products. Comparison Between DVD and Other Discs DVD Singlesided 1 layer 4.7G Singlesided 2 layers 8.5G Super VCD Analog Digital/MPEG2 Recording Method Capacity LD Doublesided 1 layer 9.
DVD OPERATION Compatible Disc Types Types DIGITAL VIDEO MPEG 4 Sizes Recorded Contents 12cm CD-DA 12cm VIDEO CD Compressed digital audio+compressed digital video (dynamic picture) 12cm SVCD: Compressed digital audio+compressed digital video (dynamic picture) 12cm DVD: Compressed digital audio+compressed digital video (dynamic picture) 12cm MPEG 4: Compressed digital + compressed digital video (dynamic picture).
DVD OPERATION PLAYBACK DVD MPEG4 SVCD VCD CD 1. Power on and place the disc (with label side facing users) to the door and the unit will draw in the disc and switch signal source to DVD mode automatically. The unit begins to read disc information. STANDBY EJECT PLAY 1 2 3 4 5 6 2. Press [ ] button to begin playing disc. 3. Press [ ] button to stop playing.
DVD OPERATION PLAY/PAUSE PLAYBACK DVD MPEG4 1. Press [ SVCD VCD CD ] button in playback status. Press [ ] button once to pause playback, display on TV screen: 2. To restore playback, press the [ ] button.
DVD OPERATION 1. Press [DISC MENU] button to display menu on TV screen for selection, operate according to the hint of menu and press number buttons to select. ROOT MENU 1. ........ PLAY 2. ........ 3. ........ 2 3 4 5 6 7 8 9 1 2. Press cursor button to select track you desired, then press [ ] button or [OK] button. Number 0 OK Cursor NOTE Press [DISC MENU] button to return to initial menu. DISC MENU The return location varies with discs.
DVD OPERATION PBC PLAYBACK SVCD VCD Enjoy PBC alternate function when playing Super VCD, VCD2.0 disc with PBC function, For example:playVCD2.0 disc. 1. Main menu displays on TV screen A: 1. ........ 2. ........ Press number button to select. For example: select main menu 1. The TV screen as show in B: 1. ........ 2. ........ 2. Submenu displays on TV screen after enter into main menu 1. 1. ........ 2. ........ 3. ........ 4. ........ 5. ........ 3. Press[ ] or [ ] button to turn to adjacent page. 4.
DVD OPERATION MEMORY DVD 1. This player can save the currently played time point automatically when you leave the current DVD disc playback (switch from DVD to card read state, switch from DVD signal source to other signal source, enter standby state in DVD mode). 2. When switching to DVD playback state again, this player can automatically search the time point saved last time to continue playing. If you want to play from the beginning, please press [ ] button twice and then press [ ] button.
DVD OPERATION DVD disc: Audio 1/2 Chinese Audio 2/2 French As for VCD, SVCD or CD disc with multiple channels, you may select audio output from left or right channel or select stereo audio output. For VCD disc, left channel records dubbing and right channel records singing, and you may select left channel for dubbing. VCD, SVCD, CD disc: Mono Left Mono Right Stereo Mix-Mono LANGUAGE RATIO SCAN SAVE NOTE Language type varies with disc recording.
DVD OPERATION REPEAT PLAYBACK OF SELECTED SEGMENT DVD MPEG4 SVCD VCD CD When playing disc, you may press [A-B] button to play your desired segment content repeatedly. 1. In normal playback, press [A-B] button at the beginning point (point A) of the segment that you desire to play repeatedly. TV screen displays: A 2. In normal playback, press [A-B] button at the ending point (point B) of the segment that you desire to play repeatedly.
DVD OPERATION PLAY FROM THE DESIRED POSITION DVD MPEG4 SVCD VCD CD Play DVD disc Inputting a certain time, title number or chapter number directly may search in the disc fast and then play forward from this position. 1. Search title and chapter. For instance, search the 2nd chapter in title 6.
DVD OPERATION 3. Select the track Press [GOTO] button until TV screen displays the following figure. Press number buttons to input track. Select Track -- /15 GOTO ZOOMING THE DISPLAYED FRAME DVD MPEG4 SVCD VCD Zoom in/out the player frame. 1. When playing a disc, press the [ZOOM] button can open the zoom in/out function, and the TV screen displays( take X2 mode as an example): The frame is magnified to 2 times of the normal size. 2.
DVD OPERATION 1 00:00 00:00 004/369 \PIC\ 2 2 .. 3 Du000 Du001 4 Du002 5 State window 4 Display the current state information. 1 DIR window 5 Display the current path. 3 6 Scroll bar window Indicate the current file's position. Preview window JPEG image preview. File window Information window 6 Display the current path's file. Display the current operation prompts.
DVD OPERATION Other basic operation methods 1. Press [ ],[ ] button may turn to the next or last page. Other functions of JPEG file 1. When playing JPEG file, pressing [ ] button will achieve preview playback function. At the same time, all JPEG files are displayed on TV screen. One page can display up to 12 pictures at most. The remaining ones are shown on the next page. Pressing [ ] button will enter the next page and [ ] button will enter the previous page.
2 3 4 5 6 7 8 9 1 0 SLEEP RATIO SCAN SAVE
DVD FUNCTION SETUP Turn on this TV, press [SOURCE] button to change source to DVD, press [SETUP] button, then press [ ] button to choose DVD item, the DVD setup menu will be displayed as follow: GENERAL SETUP General Setup Page TV Display OSD Lang Screen Saver Last Memory Wide ENG On On Go To General Setup Page 1. TV Display: This item is used to set the output picture ratio of this unit. Optional settings: Normal/PS, Normal/LB, Wide, Wide Squeeze; Default: Wide. 2.
DVD FUNCTION SETUP SDIF Setup Page SPDIF Output RAW LPCM Out 48K SPDIF/RAW SPDIF/PCM Setup SPDIF SPDIF output: This item is used to set the bit stream type of the digital output. Optional settings: SPDIF/RAW, SPDIF/PCM; Default: SPDIF/RAW LPCM output: This item is used to set the output frequency of LPCM audio data to fit for different power amplifiers. Optional settings: 48K, 96K; Default: 48K. NOTE: Only when the SPDIF output is set the SPDIF/PCM, the frequency of LPCM audio data is optional. 3.
DVD FUNCTION SETUP VIDEO SETUP Video Quality Setup Sharpness Brightness Contrast Gamma Hue Saturation Med 00 00 None 00 00 Go To Video Setup Page 1. Sharpness: This item is used to set the sharpness of video outputs. Optional settings: High, Medium, Low; Default: Med. 2. Brightness: This item is used to set the brightness of video outputs. 3. Contrast: This item is used to set the contrast of video outputs. 4. Gamma: This item is used to set the color temperature of video output.
DVD FUNCTION SETUP NOTE Audio, subtitle and disc menu language are only effective in DVD mode. If the disc is not recorded with the language you appointed, the unit will apply the language that the disc appointed to play. Select other languages: press [ ] button to move cursor to "OTHER" item, press [OK] button and then number buttons to input the language code you desired. After input finishes, press [OK] button again. 6.
DVB FUNCTION SETUP DVB-T SETUP DVB DVB- T Setup Page Area Time Zone Parental Age Antenna Power UK DIS Off Channel setup Go To DVB - T Setup Page The DVB-T Setup Page is composed of five parts: Area, Time Zone, parental Age, Antenna power, Channel Setup. Note : Press [ ] button to select different item, and press [OK] or [ ] button to enter it. Press [ ] button to return to the previous menu or to exit the current menu . 1. Area You can choose the area of your country.
DVB FUNCTION SETUP In the scan process, the scan result will be displayed in the Auto Scan window. Press [SCAN] on remote control more than 3 seconds to auto scan. Using the [ ] button to select the Auto Scan item, and press [OK] or [ ] button to select Start item, then press [OK] button; A prompting message will be displayed to request that you confirm, select OK and press the [OK] button to confirm.
DVB FUNCTION SETUP Reserve Channel If you want to watch a special program on a channel at a later time, you can reserve it. Then a reminding signal will be displayed on screen several minutes before it starts.
TROUBLESHOOTING Please check for causes of problems in accordance with the following chart before contacting maintenance personnel.
TROUBLESHOOTING DVD TROUBLESHOOTING Causes Symptom Correction Not play 1. Condensation on laser head 2. Disc not properly loaded 3. Disc not compatible with the unit 1. Switch on power and wait for 1 to 2 hours 2. Make sure label side of the disc facing up 3. Confirm whether this unit is compatible with the placed disc 1. Too large volume of connected device 2. Sound field mode not suitable for disc 1. Adjust the device volume Sound distortion No sound No image No color 2.
DISPLAY MODE SUPPORTED PC INPUT MODE Resolution Hor scanning frequency Ver scanning frequency (KHz) (Hz ) Pixel frequency (MHz) Format 640 350 31.5 70.0 25.17 DOS 720 400 31.5 70.0 28.32 DOS 640 480 31.5 60.0 25.18 DOS 640 480 37.9 72.0 31.50 VESA 640 480 37.5 75.0 31.50 VESA 800 600 35.1 56.2 36.00 VESA 800 600 37.9 60.0 40.00 VESA 800 600 48.1 72.0 50.00 VESA 800 600 46.9 75.0 49.50 VESA 1024 768 48.4 60.0 65.00 VESA 1024 768 56.5 70.11 75.
DISPLAY MODE SUPPORTED VIDEO INPUT MODE Format Hor scanning frequency ( KHZ) Ver scanning frequency (HZ) Vert scan type 720X480 31.5 60 480P 720X480 15.6 60 480i 720X576 31.2 50 576P 720X576 15.6 50 576i NOTE Specifications and designs are subject to change without notice.
