Windows PC Software
After the installation please start the software by clicking on the MAGIC
TH2plus symbol.
Connect the system via the LAN interface with your network. If you do not
have a network you can also connect the unit to your PC directly via a so-
called cross over network cable.
How to configure the LAN interface is described below (see CHAPTER 5.7.1,
Page 45).
Alternatively, you can also use the RS232 interface and a serial 1:1 cable (only
Pin 2 and Pin 3 are used, Pin 5=Ground) to connect your PC with the system.
5.4 Software update from the internet
Software updates can be downloaded from our homepage
http://www.avt-nbg.de
free of charge. Please go to our Download section and select Software. Under
MAGIC TH2plus please download the file with the ID number 430409. When
the download is completed, execute setup and follow the instructions. In ad-
dition to the PC Software, the setup also includes the Firmware for the sys-
tem. If it also has to be updated, the MAGIC TH2plus Software displays an er-
ror message when it is started. The instructions for a Firmware update are de-
scribed later on (see CHAPTER 5.8.4, Page 87).
