Technical data

PAGE 33
Operation via Display and Keypad
By the softkey OPTS (Options) the following functions which you can select
via the softkey
select are realized:
–
load : The selected Preset is loaded.
–
new : With the help of this function you can create a new Preset. All current
Operation Settings are stored as basic and can be adjusted afterwards.
– Save : The selected Preset is overwritten with the current Operation Set-
tings. For safety reasons a confirmation is required
– Delete : The currently selected Preset is deleted. For safety reasons a con-
firmation is required.
– Set Factory settings : This function resets the system into the standard
settings. Presets are not deleted.
NOTE
If the Preset has changed, you are asked if you want to save settings when
you leave the Preset menu. Via the
yes softkey the configuration is stored in
the system. This Preset is loaded automatically by the system after the unit is
connected with the power supply.
