User's Manual

Setup the video source of channel 5 or 6 to USB as point 4.3.4, then manage the USB media play from

the control panel.

Press USB5 or USB6 button to select the one which you want to manage. The VIDEO/IMAGE button is

for switching the media format between video and picture. The default setting is video format when the

video switcher power on.

There are Play/Pause, Fast Forward, Fast Backward, NEXT and BACK buttons to control the media

source from USB. The Fast Forward and Fast Backward support max 32 times speed to play the video.

2) Video Format Supporting

FLV

MPEG4(Divx), AVC(H264), FLV1

MP4

MPEG4(Divx), MPEG4(Xvid), AVC(H264),

HEVC(H265)

AVI

MPEG4(Divx), MPEG4(Xvid),

AVC(H264), HEVC(H265), MPEG2

MKV

MPEG4(Divx), MPEG4(Xvid), AVC(H264),

HEVC(H265)

MPG

MPEG1

MOV

MPEG4(Divx), AVC(H264), HEVC(H265)

3) Image format support: BMP, JPEG, PNG.

4.4 SDI PGM/AUX and Multiview Output Format

The output format of multiview is fixed at 1080p60, and for PGM output can be set by the knob. Except

PVW and PGM output, there is a AUX for choice in PGM SDI 3, you can quickly select the auxiliary output

between PVW and PGM via Menu knob. It is default as PGM after reset. There are resolution

1080P50/60/30/25/24Hz, 1080I 50/60Hz selectable for SDI/HDMI PGM and AUX outputs.
