Manual
AvMap Ultra EFISINDEX
DISCLAIMER & WARNINGS
The information displayed by the Ultra is not certied for use for VFR or IFR ights.
The Ultra is meant as an aid to VFR navigation and is not a substitute for certied EFIS.
All critical ight information is presented for reference only and must be veried by the use.
The Ultra is not a substitute for on-board instruments.
The pilot in command assumes total responsibility and risk associated with the use of this
device and remains solely responsible for ying in safe conditions.
AvMap disclaims any liability deriving from an improper use of the device, in a way that
may violate the ight and navigation rules, regulations and safety.
1. Overview 4
2. Installation 5
2.1 Location 5
2.2 Mechanical installation 5
2.3 Connections & wiring 8
3. System Calibration 10
3.1 Horizon alignment calibration (AHRS) 10
3.2 Compass calibration (magnetometer) 11
4. System Operation 14
4.1 How to operate the unit 14
4.2 PFD mode 15
4.3 HSI display mode 17
4.4 SETUP mode 19
5. Software update 20
6. Alarms and Trouble shooting 20
7. Technical Specications 22
