ISDN-Controller B1 PCI v4.0 – 9 Installation in Linux 47
Below is a schematic diagram of CAPI4Linux:
Architecture of CAPI4Linux
SUSE Linux
To simplify installation, AVM provides pre-compiled driver ar-
chives for SUSE Linux 6.3 and higher. In versions SUSE Linux
8.1 or higher, a CAPI4Linux driver is already integrated in the
operating system.
Other Distributions
The AVM ISDN-Controller B1 PCI v4.0 can be used with all
other current Linux distributions.
Installation in other distributions or kernel versions must be
adapted individually depending on the components used.
All driver components required for integration into other soft-
ware distributions or kernel versions, including the source
code and short instructions, are supplied in the “src” direc-
tory of the corresponding “tar” archive. Since the binary-only
modules contained in the drivers (for instance b1.t4) are ker-
nel-independent, they do not execute any direct kernel calls.
This means that they can be integrated into any Linux kernel.
The ISDN4Linux package is not required for the installation
of CAPI4Linux.
Fax G3
Applications
AVM CAPI 2.0
Software Development
Kit (SDK)
IP-based Applications
(WW W Browser,
FTP Client, etc.)
TCP/IP Stack
HylaFAX Interface
incl. CAPI 2.0
CAPI 2.0
B-channel Protocols: X.75, HDLC, transparent, V.110, V.120, T.90,
ISO 8208 (X.25)
D-channel Protocols: DSS1, 1TR6, NI-1, 5ESS
Layer 1 / S
0
Fax G3
Analog Services
Voice
ISDN Supplementary Services
Data
Generic PPP Stack
incl. CAPI 2.0
CAPI SoftFax G3
CAPI SoftCompression X.75 / V.42bis
CAPI SoftModem V32.bis
