42 ISDN-Controller B1 PCI v4.0 – 8 Installation in Novell NetWare 6.x, 5.x, 4.x and 3.12
8.4 Configuration of the ISDN-Controller
B1 PCI v4.0 with CAPI for the CAPI
Manager
Proceed as follows to configure and start operation of the AVM
ISDN-Controller B1 PCI v4.0 with CAPI for the CAPI Manager:
Using NetWare 6.x, the AVM ISDN-Controller B1 PCI v4.0 with
CAPI for the CAPI Manager can only be configured using the
“Small Business Edition”.
1. Enter the following command at the system console:
load inetcfg
2. The “Internetworking Configuration” window appears.
Select the “Boards” entry.
A list displays the ISDN-Controllers already configured.
3. To bind the ISDN-Controller into the operating system,
press the “Ins” key.
Please wait a moment.
4. In the “Select A Driver” dialog, select the “WHSMCAPI”
entry and press “Return”.
5. In the next window, assign a name for the ISDN-Control-
ler B1 PCI v4.0, such as AVMB1.
6. Configure the ISDN-Controller in the “WHSMCAPI Board
Configuration” window. Move the highlight to “Select to
View” and press “Return”.
7. When prompted to choose whether the ISDN-Controller
should be loaded automatically, select “Yes”.
8. In the next dialog, select the ISDN-Controller “AVMB1”
and press “Return”.
9. Then enter your parameters:
– PCI-Slot
– Reports (fixed at 2)
– Switch Type (D-channel protocol)
– Line Config (MTP = multipoint or PPT = point-to-point)
