14 ISDN-Controller B1 PCI v4.0 – 3 Installation in Windows XP
3.1 Installing the Driver Software
Once the AVM ISDN-Controller B1 PCI v4.0 has been installed
in your computer, it will be recognized automatically as a
Plug & Play device. Use the “Found New Hardware Wizard” to
configure the ISDN-Controller for operation. To do so, pro-
ceed as follows:
The following dialogs are part of the Windows XP operating
system. Consult the Windows XP manual wherever necessary.
1. Start your computer.
2. The Windows XP Plug & Play mechanism automatically
recognizes the ISDN-Controller as the “AVM ISDN-Con-
troller B1 PCI”.
3. The “Found New Hardware Wizard” is started. Confirm
with “Next”.
4. First specify the D-channel protocol to be used: DSS1
(Euro ISDN), NI-1, 5ESS, 1TR6 (obsolete). Confirm with
“Next”.
5. Enter the desired multiple subscriber numbers in the
“ISDN Phone Number and SPID Information” window.
The settings performed in this dialog are relevant only for
the NDIS WAN CAPI Driver (Internet, RAS over Dial-Up Net-
working).
6. Confirm with “Next” and finally with “Finish”.
A message appears stating that you may start operation of
the ISDN-Controller immediately. This completes the initial
driver software installation for the AVM ISDN-Controller B1
PCI v4.0 in Windows XP.
Once the driver installation is concluded, the second step is
to update the driver software from the installation CD.
We recommend installing the current driver software from
the installation CD or the ADC.
