A-Net Input
A-Net Input
You can connect a Personal Monitor Mixing System in a variety of ways.
In a typical system, audio inputs will be connected to the Input jacks on the
rear of the A-Net Input Module, such as an AN-16/i, or
routed internally in
the digital domain from a mixer’s control surface when using a
Y1
Yamaha
Output Card. From the input module, the A-Net output is connected to
the first Personal Mixer in the system. Each subsequent Personal Mixer is
connected by running a cable from the Mixer’s A-Net Output to the A-Net
Input on the next Personal Mixer. This type of connection is called a
daisy
chain
.
When using the A-16D Pro A-Net Distributor, the
daisy chain linking of
Personal Mixers is optional. Up to eight Personal Mixers can be connected
directly to the
A-Net outputs on the front of the A-16D Pro.
To
connect the A-16D Pro:
•
Connect the A-Net Output on the input module to the A-Net
Input on the A-16D Pro A-Net Distributor using a Category
5 cable. .
•
As with all A-Net compatible devices, the
cable length
between compatible components can be up to 500 feet (150
meters) long.
A-Net
Thru
The
A-Net Thru jack provides an easy way to expand a system. The A-Net
signal appearing at the Thru jack is an exact copy of the input signal. There
is no power supplied to this jack, however.
A-Net Outputs
A-Net Outputs
The eight
A-Net Outputs on the A-16D Pro A-Net Distributor all carry the
same signal. You can use any output to connect a Personal Mixer.
To connect a
Personal Mixer:
•
Connect a standard Category 5 cable from A-Net Output
#1 on the A-16D Pro A-Net Distributor to the first Personal
