INT-DDS-B-Rev1

Avigilon Control Center 5

System Integration Guide

with DDS Amadeus 5

Summary of content (10 pages)

PAGE 1
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 INT-DDS-B-Rev1
PAGE 2
© 2012 — 2014 Avigilon Corporation. All rights reserved. Unless expressly granted in writing, no license is granted with respect to any copyright, industrial design, trademark, patent or other intellectual property rights of Avigilon Corporation or its licensors. AVIGILON, CAPTURE IT WITH CLARITY, HDSM, HIGH DEFINITION STREAM MANAGEMENT (HDSM), THE BEST EVIDENCE and LIGHTCATCHER are unregistered and/or registered trademarks of Avigilon Corporation in Canada and other jurisdictions worldwide.
PAGE 3
Table of Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 For More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Upgrading from Avigilon Control Center 4 . . . . . . . . . . . . . . . 2 Client . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 4
PAGE 5
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 Introduction The Avigilon DDS integration allows you to see live and recorded video from the Avigilon Control Center System in the DDS Amadeus 5 software. Requirements Vendor Avigilon Avigilon Requirements Control Center Server Software 5 and later. Avigilon DDS integration zip file: Avigilon DDS Amadeus5 Integration.zip The file can be downloaded at http://avigilon.
PAGE 6
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 Installation Upgrading from Avigilon Control Center 4 If you are upgrading to this version of the Avigilon DDS integration software, be aware that this version of the integration is only compatible with Avigilon Control Center 5. Avigilon Control Center 5 provides the ability to organize multiple servers into Sites and share settings between servers.
PAGE 7
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 Configuration Assigning Logical IDs to Cameras In the Avigilon Control Center Client software, assign a logical ID to each camera. The Amadeus 5 software will only detect cameras with a logical ID. By default, cameras do not have a logical ID. 1. In the Avigilon Control Center Client software, right-click a camera in the System Explorer and select Setup. 2. In the camera Setup tab, click General. 3.
PAGE 8
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 Setting Up the Integration in Amadeus 5 In the Amadeus 5 software, add Avigilon Control Center servers and cameras to complete the integration. 1. In the Amadeus 5 software, open the DVR dialog box to add the Avigilon Control Center server: a. Click New. b. Give the Avigilon DVR a name and description as required. c. In the DVR Type drop down list, select Avigilon. d.
PAGE 9
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 2. Open the Camera dialog box to add cameras from the Avigilon Control Center system to the Amadeus 5 software: a. Click New. b. Give the camera a name and description as required. c. In the DVR drop down list, select the Avigilon Control Center Server you added in step 1. d. In the camera field, enter the logical ID you assigned to the camera. See Assigning Logical IDs to Cameras on page 3 for more information. e.
PAGE 10
Avigilon Control Center 5 System Integration Guide with DDS Amadeus 5 Using the Integration After the integration has been installed and configured, you can access live and recorded video from Avigilon cameras through the Amadeus 5 software. For more information, see the DDS Amadeus 5 User Guide.
