Chapter 6: Channels and Strips 77
Channel Functions
System 5 provides exceptional programmable functions for each channel:
Input, Dynamics, EQ and Filters, Aux Sends, and Pan.
Function Presets
Function Presets support storing and recalling function settings to a channel. They can be moved between Titles, systems, and
Mixer Models. Multiple functions can be included in one Preset.
Function Presets are stored in the c:\emix\system\FunctionPresets.dat file.
To store a Function Preset:
1 Press the Func Presets key from the Main Panel.
2 Press the New key on the bottom of the panel.
3 Choose a function by pressing its function select key.
Multiple functions can be selected for a Preset. They need not be from the same channel.
4 Select a Preset location from the panel.
There are 240 Presets. Use the page keys to display additional Presets.
5 Name the Preset using the CM401T’s keyboard (eight characters maximum) and press Enter.
To recall a Function Preset:
1 Press the Func Presets key from the Main Panel.
2 Select an existing Preset.
3 Press the Recall key on the bottom of the panel.
Press the Recall key quickly and it flashes to denote this will recall just one Preset to the selected channel.
Hold the Recall key down for more than 2.5 s and the key lights solid, allowing that Preset to be recalled to multiple channels.
(Not implemented on the CM402T panel.)
4 Press the Chan Select key on the desired channels to recall the Preset.
To modify a Function Preset:
1 Edit the function on the channel used to store the preset.
There is no way to retrieve this information so keep careful track of it if you want to modify the Preset.
2 Press the Store key on bottom of the panel.
3 Select the Preset to store.
