System 5 Digital Audio Mixing System User Guide34
System 5 Wave Logo
Click on the System 5 Wave logo in the bottom right of the eMix screen to display software version information and shutdown
options.
Auto Failover
When Auto Failover is checked (enabled), and an actual or potential failure of the primary DF66 is detected by the diagnostics sys-
tem, it switches the entire input audio path over to the backup DF66. Clicking on the Restore to Primary DSP button switches the
entire audio path back to the primary DF66.
Control Panel
Click the Control Panel button to change the sample rate, sync sources, IP addresses, DSP card MADI channel configuration (56
or 64 channels), and Multi-Operator Status of the attached DF66 Super Cores. DF66 software versions can be displayed from the
Control Panel, and a DF66 Restart button is provided.
View Log
Click the View Log button to display the Diagnostic Log. Avid console network communication failures and recoveries are listed
in the Diagnostic Log, along with the error status of other console components.
See “Changing Sample Rate” on page 29 to learn how to change the console sample rate.
