Chapter 14: CM403 Film/Post Module (S5 Only) 169
Speaker Re-Assign
The system automatically sends mix busses to the correct monitor bus based on the bus format. For example, when monitoring
FX1, the left bus of the section is automatically sent to the left monitor bus. It is sometimes necessary to override this assignment
and send a mix bus to a different monitor bus than was intended.
The Exp/Sel keys (above the displays on the PEC/DIR panel) can select busses within a section. When a bus is selected, the Speaker
Re-Assign panel illuminates the current monitor bus assignment. Selecting a different speaker from the panel re-assigns the bus
within the monitor matrix.
Lock
Hold down the CM403’s Wave key and press the Lock button. Lock lights when active. Hold down the Wave key and press Lock
again to disable the function.
Speaker Re-assign
Ext's
Cut
Dim
Alt 1
Spkrs
Main
Spkrs
Alt 2
Spkrs
Monitor
Insert
Spkr
Asgn
Fold
Down
Solo
Ctrl
Rec's
L
C
R
Talk
Sl
Sr
B
Lock
