Chapter 13: GPI/O Event System 161
8 Configure the Output Properties to the following settings:
To have a video switcher turn a specific camera mic channel off:
1 In the Event Configuration window, under Event List, click on the <click to add event> field.
The Add Event dialog appears.
2 Select AND as the logical operator from the menu.
3 Under Input, click on the <click to add input> field.
The Add Input Event dialog appears.
4 Select GPI from the menu and click OK.
5 Configure the Input Properties to the following settings:
6 Under Output, click on the <click to add output> field.
The Add Output Event dialog appears.
7 Select Switch Output from the menu and click OK.
8 Configure the Output Properties area to the following settings:
Channel
# 3
Switch Function Channel
Activation Value On
Input 1
Active State Off
Machine TT002
Channel # 3
Switch Function Channel
Activation Value Off
