User guide

Chapter 13: GPI/O Event System 159
5 Configure the Input Properties to the following settings:
6 Repeat steps 3–5 for any additional channel faders, but set the Channel # in step 5 to the new channel number.
7 Under Output, click on the <click to add output> field.
The Add Output Event dialog appears.
8 Select Control Room from the menu and click OK.
9 Configure the Output Properties to the following settings:
To start a Cart machine by moving a fader above a selected level:
1 In the Event Configuration window, under Event List, click the <click to add event> field.
The Add Event dialog appears.
2 Select AND as the logical operator from the menu.
3 Under Input, click on the <click to add input> field.
The Add Input Event dialog appears.
4 Select Fader from the menu and click OK.
5 Configure the Input Properties to the following settings:
6 Under Output, click the <click to add output> field.
The Add Output Event dialog appears.
7 Select GPO from the menu and click OK.
8 Configure the Output Properties to the following settings:
Channel
# 1
Activation level (dB) -50
Activation Type Below
Action Monitor A
Active State On
Channel # 2
Activation level (dB) -50
Activation Type Above
Output Number 1
Active State Closed
Pulse Length 10
Machine TT002
