Chapter 13: GPI/O Event System 155
Output Types
GP Output Types, Settings, and Activation Values
Output Type Settings Activation Values
Control Room
Monitor A
Monitor B
Monitor C
Monitor D
Control Room Cut
Control Room Dim
On
Off
GP Output
Relay Output #: (1–32)
Pulse length (0 to latch): 0 to 1000 ms
Machine: GP132 One
GP132 Two
GP132 Three
GP132 Four
GP132 Five
Open
Closed
MIDI Output
Event Type
MIDI Channel 1-16
MIDI Note 0-127
MIDI Velocity 0-127
On
Off
Switch Output
Channel
EQ
Filters
Dynamics
Mono Aux In/Out
Mono Aux Pre/Post
Stereo Aux In/Out
Stereo Aux Pre/Post
On
Off
Transport
Play
Stop
Fast Forward
Rewind
Scene
Take
Finish
Next
Prev
Goto
Recall
Recall Layout Layout #
Recall Meter Preset Meter Preset #
Recall Patch Preset Preset # 1-24
Recall Snapshot Snapshot #
Talkback Control
Mon A
Mon B
Mon C
Mon D
All Mons
Aux Bus
On
Off
