Chapter 7: Busses and Bus Masters 93
Aux, Grp, and Mix Masters
Pressing the Aux Mstrs, Grp Mstrs, or Mix Mstrs keys displays the Aux Bus, Group Bus, or Mix Bus functions, respectively, on the
Bus Master knobset.
Bus Lock
The Bus Lock key disables the following functions when activated: Bus Levels (Mix Master, Master Trims, and Leg Trims), Bus In-
serts, Bus On/Off switches. While these functions are disabled, their values may still be interrogated.
Mon Lock
The Mon Lock key disables the Control Room and Monitor levels. Dim and Cut always remain active.
All Key
The All key sets all strips to All Mode.
See “Monitoring” on page 40 for more information on monitor controls.
See
“All Mode” on page 73 for more information.
