User's Manual

MDR2400-SR, MDR5800-SR and Orion 5825-SR
Issue 10 Page 97
Object ID Object name Object Type
Access
Rights
Description
.1316.1.1.1.2.5.3 mdrmtePlatformSupport DisplayString read-only
This indicates the
hardware types supported
by the firmware:
.1316.1.1.1.2.6 mdrmteOutdoorUnit
.1316.1.1.1.2.6.1 mdrmteOuPersonalityTable SEQUENCE not-accessible
.1316.1.1.1.2.6.1.1 mdrmteOuPersonalityEntry
MdrmteOuPersonality
Entry not-accessible
.1316.1.1.1.2.6.1.1.1 mdrmteOuPersonalityIndex INTEGER read-only
.1316.1.1.1.2.6.1.1.2 mdrmteOuPersonalityActive INTEGER read-write
Indicates whether this
particular OU personality
is selected.
.1316.1.1.1.2.6.1.1.3 mdrmteOuPersonalityDataRate INTEGER read-only
Maximum raw data rate of
the personality.
.1316.1.1.1.2.6.1.1.4 mdrmteOuPersonalityModulation INTEGER read-only Modulation type.
.1316.1.1.1.2.6.1.1.5 mdrmteOuPersonalityFpgaVersion INTEGER read-only FPGA version.
.1316.1.1.1.2.6.1.1.6 mdrmteOuPersonalityRssiComp INTEGER read-only
RSSI compensation factor
used by the OU
.1316.1.1.1.2.6.1.1.7 mdrmteOuPersonalityMinTxFreq INTEGER read-only
Lowest allowed Tx
frequency
.1316.1.1.1.2.6.1.1.8 mdrmteOuPersonalityMaxTxFreq INTEGER read-only
Highest allowed Tx
frequency
.1316.1.1.1.2.6.1.1.9 mdrmteOuPersonalityMinRxFreq INTEGER read-only
Lowest allowed Rx
frequency
.1316.1.1.1.2.6.1.1.10 mdrmteOuPersonalityMaxRxFreq INTEGER read-only
Highest allowed Rx
frequency
.1316.1.1.1.2.6.1.1.11 mdrmteOuPersonalityPlanATxFreq INTEGER read-only Band plan A Tx frequency
.1316.1.1.1.2.6.1.1.12 mdrmteOuPersonalityPlanARxFreq INTEGER read-only Band plan A Tx frequency
.1316.1.1.1.2.6.1.1.13 mdrmteOuPersonalityPlanBTxFreq INTEGER read-only Band plan B Tx frequency
.1316.1.1.1.2.6.1.1.14 mdrmteOuPersonalityPlanBRxFreq INTEGER read-only Band plan B Rx frequency
.1316.1.1.1.2.6.1.1.15 mdrmteOuPersonalityPlanCTxFreq INTEGER read-only Band plan C Rx frequency
.1316.1.1.1.2.6.1.1.16 mdrmteOuPersonalityPlanCRxFreq INTEGER read-only Band plan C Rx frequency
.1316.1.1.1.2.6.1.1.17 mdrmteOuPersonalityMaxTxPower INTEGER read-only
Maximum allowed
Transmit Power
.1316.1.1.1.2.6.1.1.18 mdrmteOuPersonalityMinTxPower INTEGER read-only
Minimum allowed Transmit
Power
.1316.1.1.1.2.6.1.1.19 mdrmteOuPersonalityDefTxPower INTEGER read-only Default Transmit Power
.1316.1.1.1.2.6.1.1.20 mdrmteOuPersonalityDescription DisplayString read-only
Verbal description of this
personality
.1316.1.1.1.2.6.2 mdrmteOuPersonalities INTEGER read-only
The number of FPGA
personalities that the OU
has programmed
.1316.1.1.1.2.6.3 mdrmteOuActivePersonality INTEGER read-write
The currently active FPGA
personality
.1316.1.1.1.3.1 mdrmteInfo
.1316.1.1.1.3.1.1 mdrmteLEDTable SEQUENCE not-accessible
A group of LEDs on the
front panel of the Indoor
Unit.
.1316.1.1.1.3.1.1.1 mdrmteLEDEntry MdrmteLEDEntry not-accessible
A LED entry containing
objects describing a
particular LED.
.1316.1.1.1.3.1.1.1.1 mdrmteLEDIndex INTEGER read-only
A unique value for each
LED in the Indoor Unit. Its
value
.1316.1.1.1.3.1.1.1.2 mdrmteLEDLabel DisplayString read-only
SYSTEM Green OK,
Orange (OU/IU Comms
Error), Red (OU/IU
Comms Down).
.1316.1.1.1.3.1.1.1.3 mdrmteLEDState INTEGER read-only
The current state of the
LED - for a detailed
description of functionality,
see the mdrmteLEDLabel
entry
