MDR5800 Ordering Information:

Part no’s:

1T1/E1 Radio: 651-03853-02-H1 or 651-03853-02-L1

2T1/E1 Radio: 651-03853-02-H2 or 651-03853-02-L2

4T1/E1 Radio: 651-03853-02-H4 or 651-03853-02-L4

Each MDR5800 radio includes the following:

Part No Description QTY

651-04104-02-1

651-04104-02-2

651-04104-02-4

MDR Indoor Unit: 1xT1/E1or 2xT1/E1 or 4xT1/E1,

120 Ohm

651-03806-02H

651-03806-02L

MDR5800 Outdoor Unit 1

651-03809 MDR 5800 OU Pole Mounting Kit 1

862-01881 MDR / Orion Digital Radio System User Manual 1

651-04252 NMS Software CD 1

660-03405 RSSI Cable 1

It is possible to purchase upgrades for T1/E1 Indoor Units (upgrades to 2T1/E1 or

4T1/E1). The user contacts the factory or distributor and provides the Indoor Unit Bar

Code number details. The factory then supplies a “Tributary Code”, unique to the

Indoor Unit, which is entered using the MIB (MDR v.1 & 2+ and Orion products) or

using the NMS (v. 2+ and Orion products).
