User's Manual

MDR2400-SR, MDR5800-SR and Orion 5825-SR
Issue 10 Page 60
651-04055-02-H4 or
651-04055-02-L4
As above with BNC unbalanced payload
also available.
The MDR5800 operates from 21-56VDC (58VDC if indicated as such), optional 110-220VAC power
supply available below.
A complete link requires two radios, one must be High Band (HB) and the other a Low Band (LB).
Part No Model Number Description
651-04230-01-H08
or
651-04230-01-L08
Orion5825-ET8
Orion5825 Radio: Indoor Unit and High or Low Band
Outdoor Unit, Type-N RF output, Full 8xT1/8xE1,
8x2Mbps or 8x1.5Mbps data interface
651-04253-01-H08
or
651-04253-01-L08
Orion5825-ET8
Orion5825 Radio: Indoor Unit and High or Low Band
Outdoor Unit, Type-N RF output, Full 8xT1/8xE1,
8x2Mbps or 8x1.5Mbps data interface
The Orion 5825 operates from 21-56VDC (58VDC if indicated as such), optional 110-220VAC
power supply available below.
A complete link requires two radios, one must be High Band (HB) and the other a Low Band (LB).
Accessories & Upgrades
Part Number Description
651-04226 MDR2400SR & MDR5800SR 1+1 hot standby
combiner/splitter (4-tribs)
651-04227 ORION 5825 1+1 hot standby combiner/splitter (8-
tribs)
651-03864 Bench Power Supply 110-220VAC to 24VDC
651-07865 19" Rack Mount for Outdoor Unit (4u high)
651-03865 MDR Indoor Unit Upgrade 1xT1/E1 to 2xT1/E1
651-03866 MDR Indoor Unit Upgrade 2xT1/E1 to 4xT1/E1
651-03867 MDR Indoor Unit Upgrade 1xT1/E1 to 4xT1/E1
651-04251 MDR / Orion NMS Software CD - Spare Part
651-03809 OU Pole Mounting Kit - Spare Part
862-01881 MDR / Orion Digital Radio System User Manual -
Spare Part
660-03405 MDR / Orion Cable Assembly: RSSI Test Loom -
Spare Part
