8.6 Ordering Information
To confirm the correct order numbers, please visit www.plesseybbw.com/download.htm to download an "Order Number
Generator" utility.
Part No Model Number Description
651-03994-01-H1 or
651-03994-01-L1
MDR2400-ET1
MDR2400 Radio: Indoor Unit (DB25 balanced
payload) and High or Low Band Outdoor Unit, Type-
N RF output, high power output, Full T1/E1, 2Mbps
or 1.5Mbps data interface
651-04106-01-H1 or
651-04106-01-L1
As above with 75 Ohm, BNC unbalanced payload
also available.
651-03994-01-H2 or
651-03994-01-L2
MDR2400-ET2
MDR2400 Radio: Indoor Unit (DB25
balanced payload) and High or Low band
Outdoor Unit, Type-N RF output, high power
output, Full 2xT1/2xE1, 2x2Mbps or
2x1.5Mbps data interface
651-04106-01-H2 or
651-04106-01-L2
As above with 75 Ohm, BNC unbalanced
payload also available.
651-03994-01-H4 or
651-03994-01-L4
MDR2400-ET4
MDR2400 Radio: Indoor Unit (DB25
balanced payload) and High or Low band
Outdoor Unit, Type-N RF output, high power
output, Full 4xT1/4xE1, 4x2Mbps or
4x1.5Mbps data interface
651-04106-01-H4 or
651-04106-01-L4
As above with 75 Ohm, BNC unbalanced
payload also available.
The MDR2400 operates from 21-56VDC (58VDC if indicated as such), optional 110-220VAC power
supply available below.
A complete link requires two radios, one must be High Band (HB) and the other a Low Band (LB).
Part No Model Number Description
651-03853-02-H1 or
651-03853-02-L1
MDR5800-ET1
MDR5800 Radio: Indoor Unit (DB25 balanced
payload) and High or Low Band Outdoor Unit, Type-
N RF output, high power output, Full T1/E1, 2Mbps
or 1.5Mbps data interface
651-04055-02-H1 or
651-04055-02-L1
As above with 75 Ohm, BNC unbalanced payload
also available.
651-03853-02-H2 or
651-03853-02-L2
MDR5800-ET2
MDR5800 Radio: Indoor Unit (DB25
balanced payload) and High or Low band
Outdoor Unit, Type-N RF output, high power
output, Full 2xT1/2xE1, 2x2Mbps or
2x1.5Mbps data interface
651-04055-02-H2 or
651-04055-02-L2
As above with 75 Ohm, BNC unbalanced payload
also available.
651-03853-02-H4 or
651-03853-02-L4
MDR5800-ET4
MDR5800 Radio: Indoor Unit (DB25
balanced payload) and High or Low band
Outdoor Unit, Type-N RF output, high power
output, Full 4xT1/4xE1, 4x2Mbps or
4x1.5Mbps data interface
