The following table lists information to assist the user to select cables to be used
between the Indoor and Outdoor Units.
Interconnecting cable
Data
South Africa
STP (FTP) 4 Pairs Solid Cat 5, PVC FR UV protected Polifin
H2/J263/904 Outer Black. Outer diameter of cable : 7.3mm
± 0.5mm. (this is an “upjacketed” STP 4 Pair cable).
This is a standard
FTP Cat 5 cable that
is ‘upjacketed’ with
suitable plastic for
FR/UV (Flame
retardant/Ultra Violet)
protection.
Other cables:
1. Superior Essex BBDN CAT 5 cable P/N 04-0010-34
(7.8mm)
2. Superior Essex CAT 5 P/N 18-241-31 18-241-11
(5.1mm)
3. General Cable CAT 5 P/N 2137113 2137114
(5.6mm)
4. Belden CAT 5 P/N BC1002 (6.0mm)
Option 1 is the preferred choice. For the cables that have
diameters less the required OD, one can use one or two
pieces of heatshrink on the cable where it passes through
the gasket.
Interconnecting cable
Power
South Africa
Power 1.5mm sq stranded PVC Insulated, PVC FR UV
protected Polifin H2/J263/904 Outer Black 300/500V Temp -
20°C to +85°C. Cable outer diameter: between 7.4mm and
9mm i.e. 8.2mm ± 0.8mm.
Other cables:
Superior Essex type SJOOW flexible cable P/N 441821*
(7.4mm)
Carol Cable (General Cable) SJOW/SJO P/N 02001 18
gauge 2 conductor (7.8mm)
