5.7 MDR / Orion Test Record
Parameter Unit Site A Site B
Frequency channel plan:
Transmit
Receive
NOTE 1 : C is NOT used
for the MDR2400.
NOTE 2 : FCC
requirements (U.S. only),
page 2.
A/B/C/D
A/B/C/D
If D – List Transmit
and Receive
Frequencies [MHz]
Transmitter output power
(NOTE 2)
dBm
Receiver input level (ON) Volts
Receiver input level (ON) dBm
Receiver input level
(OFF)
Volts
Receiver input level
(OFF)
dBm
Calculated input level dBm
Fade margin dB
Frame Lock indicator Colour
Fixed attenuator DB
BER-test Hours
BER
Alarm Indicators Clear
(Yes/No)
Date
Name Signature
Performed by
Approved
by
